Sharp AL-1642CS - K Multi Manual Paper Feeding Cover Unit; L Multi Manual Paper Feeding Unit

– 17 –
K
Multi manual paper feeding cover unit
L
Multi manual paper feeding unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 CCLEZ0005RS51 AQ B Charger cleaner unit
2 XEBS730P08000 AC C Screw(3×8)
3 PCOVP0023QSJ1 AH D Multi upper cover
4 CSW-M0016RS51 AG B Side door detect switch unit
5 XEPS720P10000 AA C Screw(2×10)
6 MSPRP0110QSZ1 AD C Door switch spring
7 PSHEZ0075QSZZ AC C MB upper guide sheet
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 NROLR0922FCZ2 AR B Manual feeding roller
2 XRESP40-06000 AA C E-ring(E4)
3 NGERH0992FCZZ AB C Gear(20T)
4 MARMP0173FCZ1 AC C Arm C
5 NROLR0105QSZZ AR B Roller R
6 XPSSJ20-07000 AA C Spring pin(φ2-7)
7 NGERH0990FCZZ AB C Gear(16T)
8 NSFTZ2311FCZZ AU C Cam boss A shaft
9 LBSHZ0303FCZZ AC C M bushing C
10 LBRC-0055FCZZ AK C Multi F bracket
11 XEBS730P08000 AC C Screw(3×8)
12 PGIDM0014QSJ1 AF C DUP upper guide
13 XEBS730P06000 AA C Screw(M3×6)
14 MSPRC0049QSZZ AC C Manual feeding earth spring
15 LBOSZ1851FCZZ AC C STK clutch boss
16 MSPRC1315FCZ1 AD C Clutch spring A
17 PPIPP0109FCZ1 AC C Pipe A
18 LBOSZ0118QSZZ AE C Cam boss A1R
19 NGERH0972FCZZ AB C Gear(27T)
20 NGERH0991FCZZ AC C Gear(20.20MXL)
21 LBNDJ0013FCZ1 AE C Wire band
22 DHAI-0295QSZZ AC C Manual feeding earth harness
23 XHBS730P06000 AC C Screw(3×6)
24 XBPS730P06KS0 AB C Screw(3×6KS)
25 CPLTM0023QS03 AG C Paper plate 1
26 PPIPP0009QSZZ AD C Cam clutch sleeve
27 MSPRC1316FCZ1 AE C MF clutch spring B
28 LBOSZ1509FCZ1 AD C Cam boss B
29 RPLU-0003QSZZ AN B Multi feeding solenoid
30 MSPRC1318FCZ1 AA C Spring B
31 PTME-0179FCZZ AC C Manual paper feeding pawl B
32 PTME-0178FCZ1 AC C Manual paper feeding pawl A
33 MSPRC2175FCZZ AA C Pawl A spring
34 XBBS730P08000 AA C Screw(3×8)
35 LFRM-0010QSJZ AN D Multi frame
36 XEBS740P12000 AA C Screw(4×12)
37 LSTPP0300FCZZ AB C Stopper plate
38 MARMP0205FCZZ AF C Arm B
39 MARMP0204FCZ1 AF C Arm A
40 MHNG-0002QSZ1 AC C Arm hinge
41 MSPRC0048QSZZ AB C Arm C spring
42 PGIDM0018QSJZ AF C MB side guide R
43 PGIDM0017QSJZ AF C MB side guide L
44 PCOVP0019QSJ2 AL D Multi tray front cover
46 NGERH0021QSZZ AD C Manual feeding gear
48 LSOU-0002QSJ1 AL D Multi tray 1
49 LSOU-0003QSJ1 AH D Multi tray 2
50 MSPRC0109QSZZ AC C Spring
501 CSOU-0002RS56 AX E Multi manual paper feeding tray unit
502 CFRM-0010RS54 BG E Multi manual paper feeding unit
