Sharp AL-1642CS - T Operation PWB; Umcu Pwb

– 24 –
T
Operation PWB
U
MCU PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 QCNCM0861FCZZ AB C Connector(3pin) [CN302]
2 QCNCW1132LC1H AD C Connector(18pin) [CN301]
3
QSW-P0001ESZZ AC B Tact switch(SKQNAB010) [OLK,SCNK,MAGK,ZDWK,CLK]
QSW-P0001ESZZ AC B Tact switch(SKQNAB010) [ZUPK,10UPK,1UPK,EXUPK,EXDWK]
QSW-P0001ESZZ AC B Tact switch(SKQNAB010) [EXMODK,DUPK,CRSK,BPK,PSW]
4 VCCCCY1HH201J AA C Capacitor(50WV 200pF) [C317,C319,C326,C327]
5 VCEAJU1CW476M AB C Capacitor(16WV 47µF) [C301]
6 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C311,C323]
7
VCKYCY1HB102K AA C Capacitor(50WV 1000pF) [C302,C303,C304,C305,C306,C307,C308]
VCKYCY1HB102K AA C Capacitor(50WV 1000pF) [C309,C310,C312,C313,C314,C315,C316]
8 VCKYCY1HB223K AC C Capacitor(50WV 0.022µF) [C318,C325]
9
VHD1SS133++-1 AA B Diode(DO-34(MSD)) [D301,D302,D303,D304,D305,D306,D307]
VHD1SS133++-1 AA B Diode(DO-34(MSD)) [D308,D309,D310]
10 VHILC7935//-1 AN B IC(LC7935) [IC303]
11 VHI74HC151M-1 AD B IC(74HC151M) [IC301,IC302]
12 VHP1LHEE-002A AC B LED(Red)(1LHEE-002A) [SJAL,TPL,DPL,JPL,MPL]
13
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [DU21,DU22,PE,ME,RPL,AE,ZPL]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [DAA1,EXD,EXN,EXL,CS1L,BPL]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [SCNL,DAA2,SPFL,CS2L,3RE,2RE]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [1RE,NOR,1ENR,2ENR,PML,ONLL]
14 VHP3650AG2J-1 AL B LED(7SEGMENT)(LTC-3650AG-02J) [LEDM]
15
VRS-CY1JD101J AA C Resistor(1/16W 100Ω ±5%) [R302,R308,R309,R310,R312,R313,R314]
VRS-CY1JD101J AA C Resistor(1/16W 100Ω ±5%) [R318,R319,R321,R322,R324,R327,R336]
16 VRS-CY1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R317,R335,R338,R340,R352,R357,R360]
17
VRS-CY1JD121J AA C Resistor(1/16W 120Ω ±5%) [R328,R329,R330,R331,R332,R333,R334]
VRS-CY1JD121J AA C Resistor(1/16W 120Ω ±5%) [R341,R342,R343,R344,R345,R346,R347]
VRS-CY1JD121J AA C Resistor(1/16W 120Ω ±5%) [R348,R349,R361]
18 VRS-CY1JD151J AA C Resistor(1/16W 150Ω ±5%) [R350,R351,R358]
19 VRS-CY1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R304,R359]
20 VRS-CY1JD471J AA C Resistor(1/16W 470Ω ±5%) [R353,R354]
21
VRS-CY1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R301,R303,R305,R306,R307,R311,R315]
VRS-CY1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R316,R320,R323,R325,R326,R337,R355]
22 VRS-CY1JD511J AA C Resistor(1/16W 510Ω ±5%) [R356,R362]
23 RH-TX0003ESZZ AC B Digital transistor(KRA225S) [Q301,Q302,Q303]
(Unit)
901 CPWBF0113QSG3 BB E Operation PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 QCNCM0923FC14 AE C Connector(14pin) [CN115]
2 QCNCM0923FC24 AF C Connector(24pin) [CN101,CN122]
3 QCNCM7014SC0C AA C Connector(3pin) [CN109]
4 QCNCW0948FCZ5 AC C Connector(5pin) [CN114]
5 VHI74HC151M-1 AD B IC(74HC151M) [IC114,IC115,IC117]
6 VHITD62064AF/ AM B IC(TD62064AF) [IC123,IC126]
7 RMPTW4102QCJJ AB B Block resistor(1.0KΩ×4) [BR160,BR161,BR162,BR163]
8
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR101,BR102,BR103,BR104,BR105,BR106,BR107]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR108,BR109,BR110,BR111,BR112,BR114,BR115]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR117,BR133,BR135,BR137,BR139,BR145,BR146]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR148,BR150,BR152,BR153,BR154,BR155,BR159]
9 VRS-CZ1JD100J AA C Resistor(1/16W 10Ω ±5%) [R144,R145,R149,R267]
10
VRS-CZ1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R157,R181,R185,R195,R207,R214,R216]
VRS-CZ1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R235,R236,R237,R244,R187,R188,R282,R291]
11
VRS-CZ1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R150,R151,R152,R153,R160,R162,R163]
VRS-CZ1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R164,R165,R167,R168,R179,R180]
12 VRS-CZ1JD203J AA C Resistor(1/16W 20KΩ ±5%) [R215,R217]
13 VCCCCZ1HH330J AA C Capacitor(50WV 33pF) [C186,C188,C194,C302]
14
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C101,C107,C108,C110,C111,C112,C113]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C114,C115,C124,C128,C129,C130,C131]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C132,C133,C134,C135,C136,C137,C138]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C140,C141,C142,C143,C144,C145,C146]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C147,C148,C149,C150,C151,C152,C153]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C154,C155,C156,C157,C158,C159,C160]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C161,C162,C164,C168,C170,C173,C176,C177]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C177,C178,C179,C180,C181,C182,C183]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C184,C185,C187,C189,C193,C195,C196]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C198,C199,C205,C207,C220,C260,C283]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C285,C288,C289,C308,C323,C328]
15
VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C261,C262,C263,C264,C265,C266,C278]
VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C279,C280,C281,C290,C291,C292,C293]
VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C294,C295,C296,C297,C298,C303,C304]
VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C305,C306,C307,C309,C310,C311,C312]
16
VHDKDS121++-1 AC B Diode(KDS121) [D116,D117,D118,D125,D126,D130,D131]
VHDKDS121++-1 AC B Diode(KDS121) [D132,D136]
17 VHDKDS120++-1 AC B Diode(KDS120) [D121,D122,D123,D128,D129,D133,D134]
