Operation panel
5
Operation panel
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 CPNLH0023QS0W AR N D Panel
2 CBTN-0019QS02 AF C Copy key
3 JBTN-0020QSZZ AC C Copy key light
4 JBTN-0005QSZZ AC C % Key
5 CBTN-0050QS01 AE C Operation key R
6 JBTN-0049QSZZ AF C Operation key L
8 CPWBF0113QSG3 BB E Operation PWB
9 XEBS730P08000 AC C Screw(3×8)
10 GCAB-0063QSZZ AT D Operation cabinet
11 XEBS730P10000 AC C Screw(3×10)
12 GCAB-0064QSZZ AN D Operation panel
9
9
9
9
11
9
1
12
4
2
3
5
6
8
10
