Sharp AL-1642CS - If Pwb

– 26 –
U
MCU PWB
V
IF PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
89 VRS-CZ1JD751J AA C Resistor(1/16W 750Ω ±5%) [R196]
90 VRS-CZ1JD752J AA C Resistor(1/16W 7.5KΩ ±5%) [R191,R194,R229,R230,R231]
91 VRS-CZ1JD752F AA C Resistor(1/16W 7.5KΩ ±1%) [R156]
92 VRS-CZ1JD122F AA C Resistor(1/16W 1.2KΩ ±1%) [R171]
93 VRS-CZ1JD113F AA C Resistor(1/16W 11KΩ ±1%) [R114]
94 VRS-CZ1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R281]
95 VRS-CZ1JD153J AA C Resistor(1/16W 15KΩ ±5%) [R240,R275]
96 VRS-CZ1JD241J AA C Resistor(1/16W 240Ω ±5%) [R174,R175,R176]
97 VRS-CZ1JD272J AA C Resistor(1/16W 2.7KΩ ±5%) [R218]
98 VRS-CZ1JD432F AA C Resistor(1/16W 4.3KΩ ±1%) [R159]
99
VRS-CZ1JD330J AA C Resistor(1/16W 33Ω ±5%) [R119,R254,R255,R256,R257,R258,R259]
VRS-CZ1JD330J AA C Resistor(1/16W 33Ω ±5%) [R260,R261,R262,R276,R277,R285,R121]
100 VRS-CZ1JD303J AA C Resistor(1/16W 30KΩ ±5%) [R182,R183]
101 VRS-CZ1JD471J AA C Resistor(1/16W 470Ω ±5%) [R239]
102 VRS-CZ1JD562J AA C Resistor(1/16W 5.6KΩ ±5%) [R239]
103 VRS-CZ1JD511J AA C Resistor(1/16W 510Ω ±5%) [R186]
104 VRS-CZ1JD563J AA C Resistor(1/16W 56KΩ ±5%) [R241]
105 VCCCCZ1HH101J AA C Capacitor(50WV 100pF) [C104,C105,C190,C191,C192]
106
VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C126,C315,C316,C317,C318,C319,C320]
VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C321,C166,C341]
107 VCCCCY1HH470J AA C Capacitor(50WV 47pF) [C336]
108 VCKYCZ1HB222K AA C Capacitor(50WV 2200pF) [C211,C214,C218,C222]
109 VCKYCZ1CB223K AB C Capacitor(16WV 0.022µF) [C125,C163,C169,C197,C200]
110 VCCCCZ1HH120J AA C Capacitor(50WV 12pF) [C106,C165,C167]
111 VCCCCZ1HH220J AA C Capacitor(50WV 22pF) [C102.C103]
112 VCKYCZ1HB821K AC C Capacitor(50WV 820pF) [C201,C202,C203,C204]
113
VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C277,C313,C314,C339,C209,C210,C213]
VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C334,C335,C301]
114 VCEAGA1CW106M AA C Capacitor(16WV 10µF) [C109]
115 VCEAGA1CW226M AB C Capacitor(16WV 22µF) [C174,C286,C287,C322]
116 VCEAGA1CW476M AB C Capacitor(16WV 47µF) [C139,C217,C219]
117 VCEAGA1CW105M AA C Capacitor(16WV 1.0µF) [C206]
118 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C284]
119 VCEAGA1VW106M AA C Capacitor(35WV 10µF) [C212]
120 VCEAGA1VW476M AB C Capacitor(35WV 47µF) [C208,C276,C282,C299,C300]
121 VSKTA1505S+-1 AC B Transistor(KTA1505S) [Q101]
122 VSKRA119S++-1 AB B Transistor(KRA119S) [Q102]
123 VSKRC106S++-1 AB B Transistor(KRC106S) [Q103,Q106,Q107,Q110]
124 RFILZ0004QSZZ AM C Filter(ZJSR5101-223) [L101,L113,L123,L124,L125,L126,L127]
125 RFILN0043FCZZ AC C Filter(ZJSR5101-102) [L103,L110]
126 RH-DZ0016FCZZ AB B Diode(MA700) [D101]
127 VSKTA1281++-1 AD B Transistor(KTA1281) [Q108]
128 VSKTC3198++-1 AB B Transistor(KTC3198+) [Q109]
129 RCILZ0015QSZZ AD C Coil [L129]
(Unit)
901 CPWBX0121QS49 BY E MCU PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 DHAI-0310QSZZ AB C IF GND harness
2 QCNCW0078QSZZ AF C Connector(35Pin) [CN403]
3 QSOCN0002ESZZ AH C Connector(36Pin) [CN401]
4 QSOCN0005ESZZ AE C Connector(UBR23-4K2200) [CN402]
5 RFILN0010QSZZ AB C Coil(BLM18BB121SN1D) [L405]
6 RH-DX0001ESZZ AC B Diode(11EQS06-TA1B2) [D401]
7
VCCCCY1HH101J AA C Capacitor(50WV 100pF) [C404∼415,417∼419]
VCCCCY1HH101J AA C Capacitor(50WV 100pF) [C422,426]
8 VCCCCY1HH331J AB C Capacitor(50WV 330pF) [C416]
9 VCEAGA1CW476M AB C Capacitor(16WV 47µF) [C401,402]
10
VCKYCY1CF104Z AA C Capacitor(16WV 0.1µF) [C403,420,421,423]
VCKYCY1CF104Z AA C Capacitor(16WV 0.1µF) [C424,425,427]
11 VHEUDZS6.2B-1 AC B Zener diode(UDZS6.2B) [D402]
12 VHI74LVX16128 AP B IC(74LVX16128) [IC403]
13 RH-IX0005ESZZ AE B IC(IX0005ES) [IC402]
14 VHIUSB11AMX-1 AH B IC(USB1T11AMX) [IC401]
15 VRS-CY1JD000J AA C Resistor(1/16W 0Ω ±5%) [L403,404]
16 VRS-CY1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R424∼429]
17 VRS-CY1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R423]
18 VRS-CY1JD220J AA C Resistor(1/16W 22Ω ±5%) [R405∼419,421,422]
19 VRS-CY1JD240J AA C Resistor(1/16W 24Ω ±5%) [R402,403,430]
20 VRS-CY1JD332J AA C Resistor(1/16W 3.3KΩ ±5%) [R420]
(Unit)
901 CPWBF0114QSF1 BA E IF PWB
