Sharp AL-1642CS - WDC Power Supply PWB

– 27 –
W
DC power supply PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 0AV1690000106 AD C Ceramic capacitor(DE1007-486E222M-KH 2200PF KH) [C1,C003,C020,C021]
2 0AV1560000003 AH C Film capacitor(RE224-C 0.22µF 250V) [C2,C006]
3 0AV1690000088 AC C Ceramic capacitor(TRPE132R104K50 0.1µF 50V) [C4,C019,C114]
4 0AV1560000002 AD C Film capacitor(RE104-C 0.1µF 250V) [C5]
5 0AV1690000094 AD C Ceramic capacitor(DE1207-486E332M-KH 3300PF KH) [C7]
6 0AV1480000083 AC C Film capacitor(ECQB1H102JF4 1000pF 50V) [C8,C023]
7 0AV1480000079 AC C Film capacitor(ECQB1H103JF4 0.01µF 50V) [C9,0014]
8 0AV1390000176 AQ C Al-electrolytic capacitor(LLS2D471MHLZ 470µF 200V) [C10]
9 0AV1610000091 AC C Ceramic capacitor(DE0905-979R102K1K 1000PF 1KV) [C11.C101]
10 0AV1690000110 AD C Ceramic capacitor(TRPE132R683K50 0.068µF 50V) [C12]
11 0AV1390000107 AC C Al-electrolytic capacitor(UPJ1HR47MDH 0.47µF 50V) [C13,C106]
12 0AV1610000108 AD C Ceramic capacitor(DE1307-486R222K1K 2200PF 1KV) [C15]
13 0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C17,C018,C111,C107,C108,C109]
14 0AV1390000177 AC C Al-electrolytic capacitor(UPJ1E221MPH 220µF 25V) [C102]
15 0AV1390000181 AE C Al-electrolytic capacitor(UHD1A102MPR 1000µF 10V) [C103,C104]
16 0AV1390000178 AG C Al-electrolytic capacitor(UPJ1H821MHH 820µF 50V) [C105]
17 0AV1390000182 AG C Al-electrolytic capacitor(UHD1V102MHR 1000µF 35V) [C110]
18 0AV1390000179 AC C Al-electrolytic capacitor(UPJ1H100MDH 10µF 50V) [C112]
19 0AV1610000109 AC C Ceramic capacitor(DE0705-979R471K1K 470PF 1KV) [C113,C116]
20 0AV1390000180 AC C Al-electrolytic capacitor(UPJ1H3R3MDH 3.3µF 50V) [C115]
21 0AV3050086000 AB B Diode(1SS270A 0.15A 70V) [D1,D014,D106,D108,D111,D113,D115,D118]
22 0AV3060027000 AH B Diode(D3SB60 4A 600V) [D2]
23 0AV3060043000 AC B Rectifier(RLIN4005-E 1A 600V) [D3,D004,D012,D015]
24 0AV3070058000 AC B Zener diode(RD5.6ES 0.4W) [D5,D110,D116]
25 0AV3050036000 AF B Diode(RG1C 0.7A 1000V) [D6]
26 0AV3050019000 AF B Diode(ERA9102 0.5A 200V) [D7,D008,D010]
27 0AV3070085000 AC B Zener diode(RD33ES 0.4W) [D9]
28 0AV3070056000 AD B Zener diode(RD20ES 0.4W) [D11,D013]
29 0AV3050097000 AG B Diode(SF10LC20U 10A 200V) [D101]
30 0AV3050099000 AD B Diode(D1NL20U 1A 200V) [D102]
31 0AV3050098000 AG B Diode(SF5SC4 5A 40V) [D103]
32 0AV3070061000 AC B Zener diode(RD4.7ES 0.4W) [D104]
33 0AV3070057000 AC B Zener diode(RD30ES 0.4W) [D107]
34 0AV3070074000 AC B Zener diode(RD13ES 0.4W) [D109]
35 0AV3070081000 AC B Zener diode(RD3.9ES 0.4W) [D112,D117]
36 0AV3190008000 AN B FET(F12F50VX3 12A 500V) [Q1]
37 0AV3001015090 AD B Transistor(2SA1015 -0.15A -50V) [Q2]
38 0AV3020143999 AD B Transistor(DTC143ESA 0.1A 50V) [Q101,Q108,Q110]
39 0AV3040494000 AP B FET(2SJ494 20A 60V) [Q102]
40 0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q104,Q106,Q107,Q109,Q113]
41 0AV3001020000 AE B Transistor(2SA1020 -2A -50V) [Q105]
42 0AV3000143999 AD B Transistor(DTA143ESA -0.1A -50V) [Q112]
43 0AV2014743030 AA C Fixed carbon film resistor(RDF50S470KΩJ 470KΩ 1/2W) [R1]
44 0AV2041013020 AC B Fusing resistor(RF25S100ΩJ 100Ω 1/4W) [R2]
45 0AV2011213030 AB C Fixed carbon film resistor(RDF50S120ΩJ 120Ω 1/2W) [R3]
46 0AV2041213030 AC B Fusing resistor(RF50S120ΩJ 120Ω 1/2W) [R4]
47 0AV2013933030 AC C Fixed carbon film resistor(RDF50S39KΩJ 39KΩ 1/2W) [R5,R006]
48 0AV2011043010 AA C Fixed carbon film resistor(RDF16S100KΩJ 100KΩ 1/6W) [R7,R008]
49 0AV2012233010 AA C Fixed carbon film resistor(RDF16S22KΩJ 22KΩ 1/6W) [R9,R121,R133,R135]
50 0AV2013333010 AA C Fixed carbon film resistor(RDF16S33KΩJ 33KΩ 1/6W) [R10,R014,R026]
51 0AV2011003020 AA C Fixed carbon film resistor(RDF25S10ΩJ 10Ω 1/4W) [R11]
52 0AV2091083042 AC C Special power resistor(SPR1B0.1ΩJ 0.1Ω 1W) [R12]
53 0AV2041013010 AC B Fusing resistor(RF16S100ΩJ 100Ω 1/6W) [R13]
54 0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R15,R019,R023,R104,R122,R134]
55 0AV2016833010 AA C Fixed carbon film resistor(RDF16S68KΩJ 68KΩ 1/6W) [R16]
56 0AV2015603010 AA C Fixed carbon film resistor(RDF16S56ΩJ 56Ω 1/6W) [R17]
57 0AV2026833062 AD C Metal oxide film resistor(RSS3FB68KΩJ 68KΩ 3W) [R18]
58 0AV2016803030 AA C Fixed carbon film resistor(RDF50S68ΩJ 68Ω 1/2W) [R20]
59 0AV2015633010 AA C Fixed carbon film resistor(RDF16S56KΩJ 56KΩ 1/6W) [R21]
60 0AV2011023010 AA C Fixed carbon film resistor(RDF16S1KΩJ 1KΩ 1/6W) [R22,R113]
61 0AV2018233020 AB C Fixed carbon film resistor(RDF25S82KΩJ 82KΩ 1/4W) [R24,R025]
62 0AV2011033030 AB C Fixed carbon film resistor(RDF50S10KΩJ 10KΩ 1/2W) [R101]
63 0AV2012213010 AA C Fixed carbon film resistor(RDF16S220ΩJ 220Ω 1/6W) [R103]
64 0AV2016823010 AA C Fixed carbon film resistor(RDF16S6.8KΩJ 6.8KΩ 1/6W) [R105]
65
0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R106,R114,R115,R116]
0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R123,R124,R136,R137]
66 0AV2011533010 AA C Fixed carbon film resistor(RDF16S15KΩJ 15KΩ 1/6W) [R107]
67 0AV2990007000 AC C Metal film resistor(SN14K2C2.2KΩ D 2.2KΩ 1/6W) [R109,R111]
68 0AV2014713010 AA C Fixed carbon film resistor(RDF16S470ΩJ 470Ω 1/6W) [R110,R112]
69 0AV2990082000 AC C Metal film resistor(SN14K2C12KΩD 12KΩ 1/6W) [R119]
70 0AV2990083000 AC C Metal film resistor(SN14K2C3.44KΩD 3.44KΩ 1/6W) [R120]
71 0AV2021023052 AC C Metal oxide film resistor(RSS2FB1KΩJ 1KΩ 2W) [R130]
72 0AV2014733010 AA C Fixed carbon film resistor(RDF16S47KΩJ 47KΩ 1/6W) [R131]
73 0AV2012203010 AA C Fixed carbon film resistor(RDF16S22ΩJ 22Ω 1/6W) [R132]
74 0AV4070061000 AF C Inductor(LF-4Z-E182) [L1,L002]
75 0AV4120002000 AC C Inductor(B-01-A) [L3,L004,L101,L102,L103]
76 0AV4080007000 AH C Inductor(SK-12M-4Y) [L5]
77 0AV4120013000 AC C Inductor(T3140P3206536HW) [L104]
