– 28 –
W
DC power supply PWB
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
! 78 0AV4000134711 AS B Transformer(N-T01-347-F11) [T1]
79 0AV3160034000 AQ B Triac(TM1641PLF113) [TR1]
80 0AV5140021000 AF B Power thermistor(M5R114T3C) [TH1]
81 0AV5190002000 AF B Varistor(ENC271D-10A) [X1]
82 0AV3180000004 AL B Phototriac coupler(S21ME3Y) [PC1]
83 0AV3082561300 AF B Photo coupler(PS2561) [PC2,PC003]
84 0AV3090076000 AF B IC(MM1431ATT) [IC1,IC102]
85 0AV3090077000 AN B IC(FA3647P) [IC2]
86 0AV3090078000 AN B IC(PQ20RX11) [IC101]
87 0AV3090071000 AN B IC(PQ3RD23) [IC103]
88 0AV5030123000 AD B Connector(B02B-VT) [CN1]
89 0AV5030124000 AF B Connector(B04P-XL) [CN2]
90 0AV5030125000 AG B Connector(B16B-PHDSS-B) [CN101]
91 0AV5080010000 AQ B Relay(FTR-H1AA024V) [RL1]
92 0AV5190022000 AK B Arrestor(RA-351M-V6-Y-2) [Z1,Z002]
93 0AV5040012000 AM B Switch(SDDJE30501 10A 250V) [S1]
! 94 0AV5060058000 AK A Fuse(CES6-15A-N1 15A/125V) [F1]
! 95 0AV5060020000 AG A Fuse(TSCSA5AT-JUC 5A/125V) [F2]
96 0AV5050005000 AA C Holder(PFC5000-0203)
97 0AV5130006000 AB C Holder(TP00335-31)
98 0AV5130008000 AC C Terminal(TP00370-41)
99 0AV7100003000 AE C Insulation sheet(M-30AD-D-3)
100 0AV6114125811 AF C Heatsink(LM41258)
101 0AV8117730414 AB C Screw(NACPEW-B3×8ZF B3×8)
102 0AV8117730514 AB C Screw(NACPEW-B3×10ZF B3×10)
103 0AV7414135811 AD D Label(LV41358)
104 0AV5110012000 AB C Jumper wire 6mm(RJ-SKA-06) [RJ701,RJ717,RJ724]
105 0AV5110001000 AA C Jumper wire 10mm(RJ-SCA-06) [RJ712,RJ713,RJ715,RJ721,RJ725,RJ727]
106 0AV5110006000 AA C Jumper wire 12.5mm(RJ-SDA-06) [RJ711,RJ723,RJ726,RJ731,RJ740,RJ742,RJ744]
107
0AV5110002000 AA C Jumper wire 15mm(RJ-SEA-06) [RJ702,RJ704,RJ705,RJ714,RJ719,RJ720,RJ729]
0AV5110002000 AA C Jumper wire 15mm(RJ-SEA-06) [RJ730,RJ732,RJ733,RJ734]
0AV5110002000 AA C Jumper wire 15mm(RJ-SEA-06) [RJ735,RJ737,RJ739,RJ741]
0AV5110002000 AA C Jumper wire 15mm(RJ-SEA-06) [RJ743]
108
0AV5110004000 AA C Jumper wire 20mm(RJ-SGA-06) [RJ703,RJ706,RJ708,RJ709,RJ710,RJ722,RJ728]
0AV5110004000 AA C Jumper wire 20mm(RJ-SGA-06) [RJ736,RJ738]
(Unit)
! 901 RDENC0006QS12 BN E DC power supply PWB
