AR-M207 M165 M162 DISASSEMBLY AND ASSEMBLY 10-16
13.Others
A. Operation P.W.B.
B. Tray interface P.W.B.
No. Contents
A Operation P.W.B.
B Tray interface P.W.B.
C 2nd tray paper entry sensor / Paper empty sensor
D 2nd tray paper feed solenoid / Transport solenoid
E 2nd tray transport clutch
F 2nd tray transport roller
G 2nd tray paper feed clutch
H 2nd tray paper feed roller
I Main motor
JI/F P.W.B.
K Paper entry sensor
L Paper empty sensor
M Paper feed roller
