AR-M207 M165 M162 SIMULATIONS 7-39
49 01
Main
code
Sub
code
Contents Remark
MCU IMC PANEL
0xFF No process No process No process
0x00 OK OK OK
0x01 Data receive error (Protocol error 1) IMC sum check error Flash Rom delete error
0x02 Data receive error (Command error) IMC verify error Flash Rom write error Boot
0x03 Data receive error (Protocol error 2) Flash Rom write error (Program
section)
0x04 Loader transfer error Flash Rom write error (Common
window data)
0x05 Flash Rom delete error (Boot) Flash Rom write error (Copy window
data)
0x06 Flash Rom delete error (Program) Flash Rom write error (Scan window
data)
0x07 Flash Rom write error (Boot) Flash Rom write error (Print window
data)
0x08 Flash Rom write error (Program) Flash Rom write error (Fax window
data)
0x09 Flash Rom LOCK error (Boot)
0x0A Flash Rom LOCK error (Boo) Flash Rom write error (Fax window
data)
0x0B Sum check error (Loader) FROM size error
0x0C Sum check error (Boot) Destination error
0x0D Sum check error (Boot) Download file structure error
0x0E Sum check error (EEPROM)
0x0F EEPROM read error
0x10 EEPROM write error Sum check error (Boot not-written)
0x11 EEPROM verify error Sum check error (Loader)
0x12 Download data length error Sum check error (After Boot writing)
0x13 IMC communication error (Message
test send error)
Sum check error (Program)
0x14 IMC communication error (Message
test send error)
Sum check error (Common window
data)
0x15 IMC communication error (Download
request send error)
Sum check error (Copy window data)
0x16 IMC communication error (Download
request parameter send error)
Sum check error (Scan window data)
0x17 MCU receive error (Overrun, Fleming,
parity)
Sum check error (Print window data)
0x18 MCU receive time-out Sum check error (Fax window data)
0x19 FAX communication error Panel-MCU communication error
0x1A PANEL communication error
0x1B Download file error Download file error
FAX
0xFF No process 0x44 FONT Flash write error
0x00 OK 0x45 FONT Flash sum check error
0x01 Download impossible 0x52 Registration data work sum check error
0x02 Total data size error 0x56 Registration data format error
0x03 LOADER no file 0x57 Registration data items insufficient error
0x04 DWLD no file 0x58 Registration data items overlap error
0x05 BOOT no file 0x61 BOOT data size error
0x06 MAIN no file 0x62 BOOT work sum check error
0x07 FONT download impossible 0x63 BOOT Flash erase error
0x08 Option FLASH connection error 0x64 BOOT Flash write error
0x09 Option FLASH no match 0x65 BOOT Flash sum check error
0x11 LOADER data size error 0x71 MAIN data size error
0x12 LOADER work sum check error 0x72 MAIN work sum check error
0x21 BOOT data size error 0x73 MAIN Flash erase error
0x22 BOOT work sum check error 0x74 MAIN Flash write error
0x23 BOOT Flash erase error 0x75 MAIN Flash sum check error
0x24 BOOT Flash write error 0x81 FONT data size error
0x25 BOOT Flash sum check error 0x82 FONT work sum check error
0x31 MAIN data size error 0x83 FONT Flash erase error
0x32 MAIN work sum check error 0x84 FONT Flash write error
0x33 MAIN Flash erase error 0x85 FONT Flash sum check error
0x34 MAIN Flash write error 0x91 DWLD data size error
0x35 MAIN Flash sum check error 0x92 DWLD work sum check error
0x41 FONT data size error 0x93 DWLD Flash erase error
0x42 FONT work sum check error 0x94 DWLD Flash write error
0x43 FONT Flash erase error 0x95 DWLD Flash sum check error
