Sharp LC-40LX360H-BK - Preparation; Attaching the Stand Unit

7
ScrewsA(g2)
ScrewsA
ScrewsB(g2)
ScrewsB
ScrewsB
Preparation
• Beforeattaching(ordetaching)thestand,unplugtheACpowercordfromtheACpoweroutlet.
• Beforeperformingwork,spreadcushioningoverthesurfaceonwhichyouwillbelayingtheTV.Thiswillpreventitfrombeingdamaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
H
LC-40LX360H
-BK/
LC-40LX360H
-WH
2
3
4
Softcushion
Softcushion
Attaching the stand unit
NOTE
•Wheninstallingthestand,youneedtoputyourTVonaat
surface.Beforethat,putasoft cushion on the surface.
•Todetachthestandunit,performthestepsinreverse
order.
•Theangleofthestandisnotadjustable.
•Ascrewdriverisnotsuppliedwiththisproduct.
•Duringinstallation,pleasebecarefultoavoidgettingyour
handtrappedbetweentheTVbottomandthefloor.
1
Conrmthattherearescrewswiththestandunit.
( Four screws)
Place the TV set on the soft platform.
According to the direction of the arrow, place
the base on the whole machine. (while
holding the base to avoid it falling over).
Insert the four screws into the four holes on
the back of the TV, and tighten them.
