MX-5001N SPECIFICATIONS 2 – 5
E. Paper feed section
(1) Type
(2) Tray 1, 2 (Main unit)
(3) Manual paper feed tray (main unit)
(4) Tray 3, 4 (2-stage paper feed tray)
(5) Tray 5 (LCC)
F. Paper exit section
(1) Center tray of main unit
* A3W/12x8 paper exiting is not allowed.
(2) Shifter
Type Standard:
2-stage paper feed tray + multi manual paper
feed tray
Full option:
4-stage paper feed tray + multi manual paper
feed + LCC
Paper type setting Yes
Dehumidifying heater Service parts (Supported by kit)
Paper capacity Plain paper: 500 sheets (80 g/m
2
)
Paper size A3, B4, A4, A4R, B5, B5R, A5R, 11 x 17,
8.5 x 14, 8.5 x 13.5, 8.5 x 13.4, 8.5 x 13,
8.5 x 11, 8.5 x 11R, 7.25 x 10.5R, 5.5 x 8.5R
Paper type Plain paper, re-printed paper, recycled paper,
letter head, pre-punched paper, colored paper,
heavy paper
Feedable Paper Weight Plain paper: 16 - 28 lb bond (60 - 105g/m
2
)
Heavy paper: 28 - 110 lb bond (106 - 209g/m
2
)
Paper size setting when
shipping
AB series; Tray 1: A4, Tray 2: A3
Inch series; Tray 1: 8.5 x 11, Tray 2: 11 x 17
Paper remaining
detection
Yes (Paper empty and 3 levels)
Paper capacity Plain paper: 100 sheets (80 g/m
2
)
envelope/OHP: 20 sheets
Paper size A3W, A3, B4, A4, A4R, B5, B5R, A5R,
12 x 18, 11 x 17, 8.5 x 14 , 8.5 x 13.5,
8.5 x 13.4, 8.5 x 13, 8.5 x 11, 8.5 x 11R,
7.25 x 10.5R, 5.5 x 8.5R, envelope
Paper type Plain paper, re-printed paper, recycled paper,
letter head, pre-punched paper, colored paper,
heavy paper, thin paper, envelope, OHP,
label sheet, tab paper, glossy paper
Feedable Paper Weight Thin paper:
13 lb bond - 16 lb bond (55 - 59g/m
2
)
Plain paper:
16 lb bond - 28 lb bond (60 - 105g/m
2
)
Heavy paper:
28 lb bond - 110 lb index (106 - 209g/m
2
),
110 lb index - 140 lb index (210 - 256g/m
2
)
Paper capacity Plain paper: 500 sheets (80 g/m
2
) x 2
Paper size A3, B4, A4, A4R, B5, B5R, 11 x 17, 8.5 x 14,
8.5 x 13.5, 8.5 x 13.4, 8.5 x 13, 8.5 x 11,
8.5 x 11 R, 7.25 x 10.5R
Paper type Plain paper, re-printed paper, recycled paper,
letter head, pre-punched paper, colored paper,
heavy paper
Feedable Paper Weight Plain paper:
16 lb bond - 28 lb bond (60 - 105g/m
2
)
Heavy paper:
28 lb bond - 110 lb index (106 - 209g/m
2
)
Paper size setting when
shipping
Maximum position of paper guide width
Paper remaining
detection
Yes (Paper empty and 3 levels)
Power consumption 20W (Power is supplied from main unit)
Dimensions
(W x D x H)
with
adjuster
28-22/64 x 11-15/16 inch,
720 x 670 x 303 mm
without
adjuster
24-13/64 x 26-3/8 x 11-15/16 inch,
615 x 670 x 303 mm
Type 3,500-Sheet Large Capacity Tray
Transport speed 124 mm/s - 360 mm/s
Paper size A4, B5, 8.5" x 11"
Paper size setting Simulation setup
Paper size setting when
shipping
A4
Paper type setting Yes
Allowable paper type
and weight for paper
feed
Plain paper, re-printed paper, recycled paper,
letter head, pre-punched paper, colored paper:
16 - 28 lb bond (60 - 105g/m
2
)
Paper capacity 3,500 sheets (80 g/m
2
)
Effective height: 385 mm
Paper remaining
detection
Yes (5 levels: 100%, 75%, 50%, 25%, none)
Driving form The transport motor (DC brush-less motor)
and control PWB are built-in to LCC.
Off-center adjustment ± 3mm
(Move the regulation plate F/R to adjustment)
Power consumption
(without heater)
Normal operation
During lift-up
: 26.4W
: 40.8W
Power source 5V±5% and 24V±5% are supplied from main
unit
External dimensions
(W x D x H)
14-9/16 x 21-21/32 x 20-15/32 inch,
370 x 550 x 520 mm
Dimensions occupied by
Machine
(W x D)
14-9/16 x 21-21/32 inch, 370 x 550 (mm)
* Clearance with main unit: 235 mm
Weight Approx. 66.1 lbs, 30 kg
Thermal heater Standard equipment: AC power is supplied
from main unit. And main unit can control ON/
OFF operation.
Optional detection Auto detection system
Paper exit section Center section of the main unit
Paper exit system Face-down paper exit system
Paper exit capacity 500 sheets (When A4, 8.5 x 11)
(recommended paper for color)
Paper exit paper size/
weight
Thin paper:
13 lb bond - 16 lb bond (55 - 59g/m
2
)
Plain paper:
16 lb bond - 28 lb bond (60 - 105g/m
2
)
Heavy paper:
28 lb bond - 110 lb index (106 - 209g/m
2
),
110 lb index -140 lb index (210 - 256g/m
2
)
Shifter function Yes
Paper exit full detection Yes
Paper weight 16 lb bond - 140 lb index (55 - 256g/m
2
)
Paper size/type Offset mode Size:
Envelope, custom size, A3W
and 12 x 18 are not acceptable
Type:
Envelope, OHP, label paper and
tab paper are not acceptable
Offset width 30 mm
Integrity
* In using the
recommended paper,
A4/8.5 x 11
Non-offset Getting out:
It doesn't fall down from tray
Offset mode Getting out: within 50 mm
FR shift: within ±10 mm
JOB distance: 10 mm or more
