MX-5001N ADJUSTMENTS 5 – 1
MX-5001N
Service Manual
[5] ADJUSTMENTS
1. General
Each adjustment item in the adjustment item list is associated with
a specific Job number. Perform the adjustment procedures in the
sequence of Job numbers from the smallest to the greatest.
However, there is no need to perform all the adjustment items. Per-
form only the necessary adjustments according to the need.
Unnecessary adjustments can be omitted. Even in this case, how-
ever, the sequence from the smallest to the greatest Job number
must be observed.
If the above precaution should be neglected, the adjustment would
not complete normally or trouble may occur.
2. Adjustment item list
Job No Adjustment item list Simulation
ADJ 1 Adjust the developing doctor gap
ADJ 2 Adjust the developing roller main pole
ADJ 3 Toner density control reference value setting 25-2
ADJ 4 Adjusting high voltage values 4A Adjust the main charger grid voltage 8-2
4B Adjust the developing bias voltage 8-1
4C Transfer voltage adjustment 8-6
ADJ 5 Image density sensor (image registration
sensor) adjustment
5A Color image density sensor (image registration sensor F) calibration 44-13
5B Color image density sensor (image registration sensor F), black image
density sensor (image registration sensor R) adjustment
44-2
ADJ 6 Image skew adjustment (LSU unit) 61-4
ADJ 7 OPC drum phase adjustment 7A OPC drum phase adjustment (Auto adjustment) 50-22
7B OPC drum phase adjustment (Manual adjustment) 44-31
ADJ 8 Print engine image magnification ratio adjustment (BK) (Main scanning direction) (Print engine section) (Manual adjustment)50-10
ADJ 9 Image off-center adjustment (Print engine section) 50-10
ADJ 10 Image registration adjustment (Print engine
section)
10A Image registration adjustment (Main scanning direction, sub scanning
direction) (Auto adjustment)
50-22
10B Image registration adjustment (Main scanning direction) (Manual
adjustment)
50-20
10C Image registration adjustment (Sub scanning direction) (Manual
adjustment)
50-21
ADJ 11 Scan image distortion adjustment 11A Scanner (reading) unit parallelism adjustment
11B Scan image (sub scanning direction) distortion adjustment
11C Scan image (main scanning direction) distortion adjustment
11D Scan image distortion adjustment (Whole scanner unit)
ADJ 12 Scan image focus adjustment (CCD unit
position adjustment)
12A Document table mode image focus adjustment
12B DSPF mode image focus adjustment
ADJ 13 RSPF/DSPF parallelism adjustment 13A RSPF height adjustment
13B RSPF diagonal adjustment
13C DSPF levelness adjustment
13D DSPF skew adjustment
ADJ 14 Scan image magnification ratio adjustment
(Document table mode)
14A Scan image magnification ratio adjustment (Main scanning direction)
(Document table mode)
48-1
14B Scan image magnification ratio adjustment (Sub scanning direction)
(Document table mode)
48-1
ADJ 15 Scan image magnification ratio adjustment
(RSPF/DSPF mode)
15A Scan image magnification ratio adjustment (Main scanning direction)
(RSPF mode)
48-1
15B Scan image magnification ratio adjustment (Sub scanning direction)
(RSPF mode)
48-1
15C Scan image magnification ratio adjustment (Main scanning direction)
(DSPF mode)
48-1
15D Scan image magnification ratio adjustment (Sub scanning direction)
(DSPF mode)
48-1
ADJ 16 Scan image off-center adjustment 16A Scan image off-center adjustment (Document table mode) 50-12
16B Scan image off-center adjustment (RSPF mode) 50-12
16C Scan image off-center adjustment (DSPF mode) 50-12
ADJ 17 Print area (Void area) adjustment (Print engine section) 50-10/50-1
ADJ 18 Copy image position, image loss adjustment 18A Copy image position, image loss adjustment (Document table mode) 50-1 (50-2)
18B Document scan position adjustment (RSPF mode) 53-8
18C Document scan position adjustment (DSPF mode) 53-8
18D Copy image position, image loss adjustment (RSPF mode) 50-6 (50-7)
18E Copy image position, image loss adjustment (DSPF mode) 50-6 (50-7)
ADJ 19 Print lead edge image position adjustment (Printer mode) (Print engine section) 50-5
