Sharp MX-5000N Service Manual

MX-5001N CONSUMABLE PARTS 3 – 3
3. Maintenance parts list
A. U.S.A/Canada/South and Central America
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller unit x 1 200K MX-410UH
2-1 Heat roller kit Separation pawl upper x 4 300K MX-410HK 41-sheet machine for 120V
Separation pawl lower x 4
Upper separation pawl spring x 4
Lower separation pawl spring x 4
Upper thermistor x 1
Lower thermistor x 1
Upper thermistor PA (Non-contact thermistor P) x 1
Lower heat roller unit x 1
External heating belt unit x 1
2-2 Heat roller kit Separation pawl upper x 4 300K MX-500HK 50-sheet machine for 120V
Separation pawl lower x 4
Upper separation pawl spring x 4
Lower separation pawl spring x 4
Upper thermistor x 1
Lower thermistor x 1
Upper thermistor PA (Non-contact thermistor P) x 1
Lower heat roller unit x 1
External heating belt unit x 1
3 Web cleaning kit Web unit x 1 150K MX-410WC
Lower CL roller CJ2 x 1
Lower CL roller bearing x 2
CL pressure SP CJ2 x 2
4 Primary transfer kit PTC unit x 1 300K MX-310Y1
Primary transfer belt x 1
Transfer cleaning blade x 1
Primary transfer roller x 4
Belt drive gear x 1
5 Secondary transfer kit Secondary transfer belt x 1 300K MX-410Y2
Secondary transfer roller x 1
Secondary transfer idle gear x 1
6 Filter kit Ozone filter CJ x 1 150K MX-450FL
7 PS paper dust removing unit PS paper dust removing unit x 1 150K MX-310PD
8 Waste toner box kit Waste toner box unit (with LSU cleaner x 3) x 1 40K MX-310HB 5% coverage for each
color; 43% color ratio
9 DV seal kit DV blade N kit x 1 Black: 150K,
Color: 100K
MX-310DS
DV side seal F x 1
DV side seal R x 1
Toner filter unit x 3
10 Main charger kit Main charger unit x 1 Black: 150K,
Color: 100K
MX-310MK
Drum cleaning blade x 1
Cleaning Gum P2 x 1
11 Staple cartridge Staple cartridge x 3 5000 times x 3 AR-SC2 For 4K finisher
(MX-FN11)
12 Staple cartridge Staple cartridge x 3 2000 times x 3 AR-SC3 For saddle stitch finisher
(MX-FN10)
13 Staple cartridge Staple cartridge x 3 5000 times x 3 MX-SCX1 For inner finisher/
saddle stitch finisher
(MX-FNX9/MX-FN10)
14 Stamp cartridge Stamp cartridge x 2 — AR-SV1
15 Primary transfer belt unit Primary transfer belt unit (For service purpose) x 1 — MX-410U1
16 Secondary transfer belt unit Secondary transfer belt unit (For service purpose) x 1 — MX-410U2
17-1 Fusing unit Fusing unit (For service purpose: Heater lamp 120V) x 1 — MX-410FU1 41-sheet machine for 120V
17-2 Fusing unit Fusing unit (For service purpose: Heater lamp 120V) x 1 — MX-500FU1 50-sheet machine for 120V
1
1
1
: Oct. 24 2008
