MX-5001N SIMULATION 6 – 129
<Print pattern of Item A>
Item/Display Content Setting range Default value
A PRINT PATTERN
(1,2,9 - 11,15 - 19,21,22,29)
Specification of the print pattern
(* For details, refer to the description
below.)
1 - 58
(Printable only 1, 2, 9 - 11, 15 - 19, 21, 22, 29)
1
B DOT1 (DOT1>=2 IF A:2,11) Setting of print dot number (M parameter)
(Self print pattern: m by n)
1-255
(Pattern 2,11: 2-255 except above: 1-255)
1
C DOT2 (DOT2>=2 IF A:2,11) Setting of blank dot number
(N parameter) (Self print pattern: m by n)
0-255
(Pattern2,11: 2-255 except above: 0-255)
254
D DENSITY (FIXED "255" IF A: 9) Used to specify the print gradation. 1-255
(Pattern 9: 255 Fixed except above:1-255)
255
E MULTI COUNT Number of print 1 - 999 1
F EXPOSURE
(2 - 8 IF A: 15 - 19)
THROUGH Exposure mode
specification
No process (through) 1-8
(Pattern 15-19: 2-8 except above:1-8)
18
(STANDARD
DITHER)
CHAR/PIC Text/Printed Photo 2
CHAR/PRPIC Text/ Photograph 3
CHAR Text 4
PRINT PIC Printed Photo 5
PRINT PAPER Photograph 6
MAP Map 7
STANDARD
DITHER
Dither without
correction
8
G PAPER MFT Tray selection Manual paper feed 1 - 6 1 2 (CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
LCC LCC 6
H DUPLEX YES Duplex print
selection
Yes 0 - 1 0 1 (NO)
NO No 1
I PAPER TYPE PLAIN Paper type Standard paper 1 - 4 1 1 (PLAIN)
Pattern
No.
Content
Pattern
generating
section
NOTE
1 Grid pattern LSU-ASIC
2Dot print -
9 Each color 10%
area (A4/A4E)
density print
Each interval is 41.86mm
(989dot).
10 8-color belt print
11 4-color dot print
(sub scan)
15 16 gradations
+ M by N
(center gradations
only): Sub scan)
MFP ASIC • When all colors are
selected, print is made in
CMY.
• 16 gradations print
• The gradation is changed
for every 256 dots.
16 16 gradations
+ M by N
(center gradations
only): Main scan)
17 All background
(half tone)
Half tone
(MFP ASIC
rear
process)
When all colors are
selected, print is made in
CMY.
18 256 gradations
pattern
(Other dither)
• When all colors are
selected, print is made in
CMY.
• 16 gradations are printed
in the main scanning
direction, and feedback is
made, and the next 16
gradations are printed.
(16 x 16 patch print)
• Print is made from 255
gradations, and 0-254
gradations are printed.
19 256 gradations
pattern
(For text dither)
20 - - -
21 4-point dot print
(main scan)
LSU-ASIC
22 Slant line
29 Dot print 1200dpi
