MX-5001N SELF DIAG AND TROUBLE CODE 7 – 14
F1-45 Saddle staple trouble
F1-47 Saddle paper transport motor trouble
F1-50 Main unit - Finisher combination error
F2-22 Discharge lamp trouble (K)
F2-23 Discharge lamp trouble (C)
F2-24 Discharge lamp trouble (M)
F2-25 Discharge lamp trouble (Y)
F2-39 Process thermistor trouble
F2-40 Toner density sensor trouble (BLACK)
Trouble content Abnormality of the staple unit drive motor in the
saddle section.
Detail PCU
Cause Saddle staple motor trouble.
Finisher control PWB trouble.
Home position sensor trouble.
Harness and connector connection trouble.
Check & Remedy Use SIM3-3 to check the operation of the saddle
staple motor.
Check connection from the control PWB to the motor.
Turn OFF/ON the power.
Replace the control PWB.
Replace the sensor.
Trouble content Abnormality in the drive roller oscillation motor in the
finisher saddle transport section.
Detail PCU
Cause Saddle paper transport motor trouble.
Finisher control PWB trouble.
Harness and connector connection trouble.
Fuse blown (24V line).
Check & Remedy Use SIM3-3 to check the operation of the saddle
paper transport motor.
Check connection from the control PWB to the motor.
Replace the control PWB.
Replace the sensor.
Trouble content
Detail PCU
Cause The finisher which is not supported by the main unit
model is installed.
Finisher control PWB trouble.
Check & Remedy Install a proper finisher.
Replace the finisher control PWB.
Trouble content A trouble is detected when the discharge lamp open
sensor is open for 1 sec after turning ON the
discharge lamp.
Detail PCU
Cause Contact trouble between the discharge lamp PWB
(K) and the PCU PWB.
Discharge lamp PWB (K) trouble.
PCU PWB trouble.
Check & Remedy Replace the discharge lamp PWB (K).
Check the harness and the connector.
Replace the PCU PWB.
Trouble content A trouble is detected when the discharge lamp open
sensor is open for 1 sec after turning ON the
discharge lamp.
Detail PCU
Cause Contact trouble between the discharge lamp PWB
(C) and the PCU PWB.
Discharge lamp PWB (C) trouble.
PCU PWB trouble.
Check & Remedy Replace the discharge lamp PWB (C).
Check the harness and the connector.
Replace the PCU PWB.
Trouble content A trouble is detected when the discharge lamp open
sensor is open for 1 sec after turning ON the
discharge lamp.
Detail PCU
Cause Contact trouble between the discharge lamp PWB
(M) and the PCU PWB.
Discharge lamp PWB (M) trouble.
PCU PWB trouble.
Check & Remedy Replace the discharge lamp PWB (M).
Check the harness and the connector.
Replace the PCU PWB.
Trouble content A trouble is detected when the discharge lamp open
sensor is open for 1 sec after turning ON the
discharge lamp.
Detail PCU
Cause Contact trouble between the discharge lamp PWB
(Y) and the PCU PWB.
Discharge lamp PWB (Y) trouble.
PCU PWB trouble.
Check & Remedy Replace the discharge lamp PWB (Y).
Check the harness and the connector.
Replace the PCU PWB.
Trouble content
Detail PCU
Cause Process thermistor trouble.
Process thermistor harness connection trouble.
PCU PWB trouble
Check & Remedy Replace the process thermistor.
Check connection of the harness and the connector.
Replace the PCU PWB.
Trouble content
Detail PCU
Cause Toner density sensor output abnormality (Sample
level 25 or less, or 231 or above)
Connection trouble of the connector and the
harness.
Developing unit trouble. PCU PWB trouble
Check & Remedy Replace the toner density sensor.
Check connection of the connector and the harness.
Replace the developing unit.
Replace the PCU PWB.
