3. Perform procedures described in Table 3.
Table 3. Program loader BOX connection procedures
After performing procedures described in Table 3, confirm the LCD is data & time and press FUNCTION 9 8 # 6
START , “PRINTER DOWNLOAD” appears on the LCD.
And press down the START key, “DOWNLOADING WT” appears on the LCD.
↓
Proceed to 4.
FAX PWB rewriting
1 Before connecting the PC
and Program loader BOX
with RS-232C cable.
Set the switches of Program
loader BOX as follows.
(a) MAIN SW OFF (down)
(b) CALIBRATION OFF
(down)
(c) BATSW OFF (down)
(d) PARK SW OFF (down)
(e) IC Voltage to 3.3V (down)
(f) MODE to DOWNLOAD
(down)
2 After connecting the PC
and Program loader BOX
with RS-232C cable. (1*)
Set the switch of Program
loader BOX as follows.
(g) MAIN SW ON (up)
3 Power supply to the FAX
machine.
Plug the power cable of the
FAX machine to the outlet.
(2* TYPE1: FAX ENGINE
FLASH ROM Only.)
4 Connect Program loader
BOX and the Control PWB
of the FAX machine
(CNPRG) with Main
Cable. (3*)
---
1*: Connect one end of RS-232C cable to the COM port of the PC and the other end to RS-232C DSUB 9PIN of
Program loader BOX.
2*(TYPE1: FAX ENGINE FLASH ROM Only.):
Press and hold down the keys 1 simultaneously while turning on the FAX machine and until “DOWNLOAD MODE” appears.
3*: Perform the procedure 3 before 4 . (Turn on the Program loader BOX and the FAX machine before connecting
Main cable and the FAX machine.)
Connect one end of Main cable to the connector of the Control PWB connector for the FAX machine (CNPRG) (refer to Fig. 3), and the other
end to CN1 of Program loader BOX.
TYPE2: PRINTER ENGINE FLASH ROM
