Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 14 –
[8] Printer PWB unit
112 VS2SC3052F/-1 AD B Transistor(2SC3052F) [Q101]
113 VRS-HT3AAR91J AB C Resistor(1W 0.91Ω ±5%) [R1]
114 VRS-HT3AAR91J AB C Resistor(1W 0.91Ω ±5%) [R2]
115 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R105]
116 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R106]
117 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R107]
118 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R108]
119 VRS-CY1JB512J AA C Resistor(1/16W 5.1KΩ ±5%) [R109]
120 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R110]
121 VRS-CY1JB362F AC N C Resistor(1/16W 3.6KΩ ±1%) [R111]
122 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R112]
123 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R113]
124 VRS-CY1JB105J AA C Resistor(1/16W 1MΩ ±5%) [R114]
125 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R116]
126 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ±5%) [R117]
127 VRSCY1JB7871F AA C Resistor(1/16W 7.87KΩ ±1%) [R118]
128 VRSCY1JB1000F AA C Resistor(1/16W 100Ω ±1%) [R119]
129 VRS-CY1JB202F AC N C Resistor(1/16W 2.0KΩ ±1%) [R120]
130 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R121]
131 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R122]
132 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R125]
133 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R126]
134 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R127]
135 VRS-CY1JB473J AA C Resistor(1/16W 47KΩ ±5%) [R128]
136 VRS-CY1JB121J AA C Resistor(1/16W 120Ω ±5%) [R129]
137 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R134]
138 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R135]
139 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R136]
140 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R138]
141 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R139]
142 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R140]
143 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R143]
144 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R144]
145 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ±5%) [R145]
146 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R146]
147 VRS-CY1JB121J AA C Resistor(1/16W 120Ω ±5%) [R147]
148 VRS-CY1JB473J AA C Resistor(1/16W 47KΩ ±5%) [R148]
149 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R151]
150 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R152]
151 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R153]
152 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R154]
153 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R155]
154 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R156]
155 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R157]
156 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R158]
157 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R159]
158 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R160]
159 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R161]
160 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R162]
161 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R163]
162 VRS-CY1JB330J AA C Resistor(1/16W 33Ω ±5%) [R164]
163 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R165]
164 VRS-CY1JB512J AA C Resistor(1/16W 5.1KΩ ±5%) [R167]
165 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R168]
166 RR-TZ3012SCJ0 AB B Resistor array(100Ωx4) [RA1]
167 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA2]
168 RR-DZ1115AFZZ AC B Resistor array(10KΩx4) [RA3]
169 RR-TZ3012SCJ0 AB B Resistor array(100Ωx4) [RA4]
170 RR-TZ3012SCJ0 AB B Resistor array(100Ωx4) [RA5]
171 RR-TZ3012SCJ0 AB B Resistor array(100Ωx4) [RA6]
172 RR-TZ3012SCJ0 AB B Resistor array(100Ωx4) [RA7]
173 RCRMA2009XHZZ AG N B Crystal(48MHz) [X1]
(Unit)
901 DCEKP440CXH01 BU N E Printer PWB unit(Within ROM)
[9] Power supply PWB unit
1 0KY0L551A0010 AE C Ferrite beads(BL02RN1) [BEA1]
2 0KY0W000A0050 AC C Wire(1/4W 0Ω) [BEA101]
3 0KY0C245Q1040 AM C Film capacitor(275WV 0.1µF) [C1]
4 0KYC3126KS151 AR N C Electrolytic capacitor [C5]
5 0KY0C176Q4720 AL C Ceramic capacitor(4700PF) [C6]
6 0KY0C176Q4720 AL C Ceramic capacitor(4700PF) [C7]
7 0KY0C1A9R2210 AG C Ceramic capacitor(1KWV 220PF) [C8]
8 0KYC1102EC472 AC C Ceramic capacitor(50WV 4700PF) [C9]
9 0KYC1102CC333 AC N C Ceramic capacitor(25WV 0.033µF) [C10]
10 0KY0C1Q1E1010 AD C Ceramic capacitor(50WV 100PF) [C11]
11 0KY0C3A0E1510 AL N C Electrolytic capacitor(50WV 150µF) [C101]
12 0KY0C3A0B3310 AL C Electrolytic capacitor(16WV 330µF) [C102]
13 0KY0C1Q2B1040 AD C Ceramic capacitor(16WV 0.1µF) [C110]
14 0KY0K207B0020 AK C Connector(2pin) [CNAC]
