Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 13 –
[8] Printer PWB unit
32 VCCCCY1HH100D AA C Capacitor(50WV 10PF) [C137]
33 VCCCCY1HH100D AA C Capacitor(50WV 10PF) [C138]
34 VCCCCY1HH100D AA C Capacitor(50WV 10PF) [C139]
35 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C140]
36 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C141]
37 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C142]
38 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C143]
39 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C144]
40 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C145]
41 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C146]
42 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C147]
43 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C148]
44 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C150]
45 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C151]
46 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C153]
47 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C154]
48 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C156]
49 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C157]
50 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C158]
51 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C159]
52 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C160]
53 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C161]
54 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C162]
55 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C167]
56 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C168]
57 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C169]
58 VCKYCY1HB272K AB C Capacitor(50WV 2700PF) [C171]
59 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C172]
60 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C173]
61 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C174]
62 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C175]
63 VCKYCY1HB103K AA C Capacitor(50WV 0.01µF) [C176]
64 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C177]
65 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C181]
66 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C183]
67 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C184]
68 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C185]
69 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C186]
70 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C187]
71 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C188]
72 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C190]
73 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C191]
74 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C197]
75 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C198]
76 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C200]
77 VCCCCY1HH331J AB C Capacitor(50WV 330PF) [C201]
78 VCCCCY1HH331J AB C Capacitor(50WV 330PF) [C202]
79 VCCCCY1HH331J AB C Capacitor(50WV 330PF) [C203]
80 VCCCCY1HH331J AB C Capacitor(50WV 330PF) [C204]
81 VCCCCY1HH331J AB C Capacitor(50WV 330PF) [C205]
82 QCNCM7014SC0B AD C Connector(2pin) [CNCRMT]
83 QCNCM7014SC0D AB C Connector(4pin) [CNFDMT]
84 QCNCW2556SC1B AG N C Connector(12pin) [CNHEAD1]
85 QCNCW2556SC1B AG N C Connector(12pin) [CNHEAD2]
86 QCNCM2482SC2H AG C Connector(28pin) [CNPRINT]
87 VHDU1GC44//-1 AC B Diode(U1GC44) [D1]
88 VHDSS16////-1 AF N B Diode(SS16) [D2]
89 VHDSS14////-1 AF N B Diode(SS14) [D3]
90 VHDSS14////-1 AF N B Diode(SS14) [D4]
91 VHDSS14////-1 AF N B Diode(SS14) [D5]
92 VHDSS14////-1 AF N B Diode(SS14) [D6]
93 VHDSS14////-1 AF N B Diode(SS14) [D7]
94 VHDSS14////-1 AF N B Diode(SS14) [D8]
95 VHD1SS355//-1 AB B Diode(1SS355) [D100]
1 96 QFS-L1027YCZZ AE B Fuse [FU1]
97 RH-IX2314XHZZ BF N B IC,Hurricane 208(LQFP208) [IC1]
98 RH-IX2322XHZZ AM N B IC,EEPROM(S-24CO4B) [IC2]
99 VHIPC901054-1 AY B IC,Thunderbolt(PLCC44) [IC3]
100 VHIPQ1X251M-1 AL N B IC,+2.5V Regulater(PQ1X251M2ZP) [IC4]
101 RH-IX2289XHZZ AZ N B IC,DRAM 4M(IS41LV16256) [IC5]
102 VHIF001/TA71F BA N B IC FLASH ROM(1M)Ver.TA71F(DROM-440CXH0A) [IC6]
103 RCILF2175XHZZ AL N C Coil(680µH) [L1]
104 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L100]
105 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L101]
106 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L102]
107 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L103]
108 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L104]
109 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [L105]
1 110 VHPGP1S094HCZ AG N B P-IN sensor(GP1S094HCZ) [PI1]
111 VS2SC3052F/-1 AD B Transistor(2SC3052F) [Q100]
