Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 8 –
[6] Control PWB unit
1 UBATL2049SCZZ AF B Battery(CR2032T23) [BAT1]
2 VCEAPSOJC157M AF N C Capacitor(6WV 150µF) [C1]
3 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C2]
4 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C4]
5 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C5]
6 VCEAGA0JW227M AD C Capacitor(6.3WV 220µF) [C6]
7 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C7]
8 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C8]
9 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C9]
10 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C10]
11 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C11]
12 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C13]
13 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C14]
14 VCEAGA0JW227M AD C Capacitor(6.3WV 220µF) [C15]
15 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C16]
16 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C17]
17 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C18]
18 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C18]
19 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C19]
20 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C20]
21 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C21]
22 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C22]
23 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C23]
24 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C24]
25 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C25]
26 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C26]
27 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C27]
28 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C28]
29 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C29]
30 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C30]
31 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C31]
32 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C32]
33 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C33]
34 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C100]
35 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C101]
36 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C102]
37 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C103]
38 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C104]
39 VCKYCY1HB223K AC C Capacitor(50WV 0.022µF) [C114]
40 VCKYCY1HB472K AA C Capacitor(50WV 4700PF) [C115]
41 VCKYCY1HB103K AA C Capacitor(50WV 0.01µF) [C116]
42 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C126]
43 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C127]
44 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C131]
45 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C137]
46 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [C143]
47 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C148]
48 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C149]
49 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C150]
50 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C151]
51 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C152]
52 VCCCCY1HH470J AA C Capacitor(50WV 47PF) [C160]
53 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C166]
54 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C167]
55 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C170]
56 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C171]
57 VCCCCY1HH3R0C AA C Capacitor(50WV 3PF) [C183]
58 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C184]
59 RCILZ2179XHZZ AE N C Coil(BLM18HG102SNID) [C186]
60 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C187]
61 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C193]
62 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C194]
63 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C195]
64 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C196]
65 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C197]
66 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C198]
67 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C209]
68 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C210]
69 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C211]
70 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C212]
71 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C213]
72 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C214]
73 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C215]
74 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C216]
75 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C217]
76 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C218]
77 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C219]
78 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C220]
79 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C221]
80 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C222]
