Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 9 –
[6] Control PWB unit
81 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C223]
82 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C225]
83 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C226]
84 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C227]
85 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C228]
86 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C229]
87 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C230]
88 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C233]
89 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C234]
90 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C235]
91 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C236]
92 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C237]
93 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C238]
94 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C239]
95 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C243]
96 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C244]
97 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C245]
98 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C248]
99 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C249]
100 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C250]
101 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C251]
102 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C253]
103 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C254]
104 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C255]
105 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C256]
106 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C257]
107 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C258]
108 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C259]
109 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C260]
110 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C261]
111 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C265]
112 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C266]
113 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C267]
114 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C268]
115 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C269]
116 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C271]
117 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C272]
118 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C273]
119 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C274]
120 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C275]
121 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C276]
122 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C277]
123 QCNCM7014SC0G AB C Connector(7pin) [CNCIS]
124 QCNCW2500SC1B AF C Connector(12pin) [CNLIUA]
125 QCNCM7014SC0F AB C Connector(6pin) [CNMT]
126 QCNCM7014SC1B AD C Connector(12pin) [CNPN]
127 QCNCM7014SC0C AA C Connector(3pin) [CNPRG]
128 QCNCM2482SC2H AG C Connector(28pin) [CNPRT]
129 QCNCM7014SC0H AB C Connector(8pin) [CNPW]
130 QCNCM2401SC0B AA C Connector(2pin) [CNSP]
131 VHD1SS355//-1 AB B Diode(1SS355) [D104]
132 VHD1SS355//-1 AB B Diode(1SS355) [D105]
133 VHD1SS355//-1 AB B Diode(1SS355) [D106]
134 VHD1SS355//-1 AB B Diode(1SS355) [D107]
135 VHDHRW0202B-1 AD B Diode(HRW0202B) [D108]
1 136 QFS-L1026YCZZ AE B Fuse(KAB5002 501) [FU100]
1 137 QFS-L2016XHZZ AD B Fuse(KAB5002 201) [FU101]
138 VHIKID65001AP AE B IC,Driver(KID65001AP) [IC2]
139 RH-IX2288SCZZ BE N B IC,16M DRAM(1S41LV8205) [IC4]
140 VHIF004/TA77G BU N B IC FLASH ROM(4MB)Ver.TA77G(DROM-984RXH0A) [IC5][UX-B700U]
VHIF004/TA95A BU N B IC FLASH ROM(4MB)Ver.TA95A(DROM-986RXH0A) [IC5][FO-B1600U]
141 RH-IX0013ESZZ AY N B IC,ROM(4MB) [IC6]
142 VHINJM2113M-1 AG B IC,Speaker AMP.(NJM2113M) [IC8]
143 RH-IX2306SCZZ BF N B IC,Original Asic(µPD65944) [IC12]
144 VHISCE214//-1 BN N B IC,FAX ENGINE(SCE214) [IC16]
145 RH-IX2168XHZZ AZ B IC,DRAM(4Mb)(GLT441L08) [IC19]
146 VHIPST596IN-1 AE B IC,RESET IC(PST596INR) [IC20]
147 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L100]
148 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L101]
149 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L102]
150 VRS-CY1JB150J AA C Resistor(1/16W 15Ω ±5%) [L103]
151 VRS-TS2AD3R0J AA C Resistor(1/10W 3Ω ±5%) [L104]
1 152 VHPGP1S58V/-1 AE B Original sensor(GP7S58VS) [PH1]
1 153 VHPGP1S58V/-1 AE B Front sensor(GP7S58VS) [PH2]
1 154 VHPGP1S58V/-1 AE B DR sensor(GP7S58VS) [PH100]
155 VS2SJ243///-1 AD B Transistor(2SJ243) [Q1]
156 VS2SA1530AS-1 AC B Transistor(2SA1530AS) [Q100]
157 VSRT1N141C/-1 AB B Transistor(RT1N141C) [Q101]
158 VSRT1N141C/-1 AB B Transistor(RT1N141C) [Q103]
159 VRS-HT3DA221J AB C Resistor(2W 220Ω ±5%) [R1]
