Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 15 –
[9] Power supply PWB unit
15 0KY0K202B0080 AE C Connector(B8B-PH-K-S) [CNPW]
16 0KY0D251A0020 AD B Diode(1SS133) [D3]
17 0KY0D251A0020 AD B Diode(1SS133) [D4]
18 0KY0D492A0050 AG N B Zener diode(UDZ S9.1) [D5]
19 0KY0D251A0020 AD B Diode(1SS133) [D6]
20 0KY0D466A1050 AE B Zener diode(HZS30) [D8]
21 0KY0D157A0060 AG B Diode(ERA15-06) [D10]
22 0KY0D157A0060 AG B Diode(ERA15-06) [D11]
23 0KY0D157A0060 AG B Diode(ERA15-06) [D12]
24 0KY0D157A0060 AG B Diode(ERA15-06) [D13]
25 0KYD2049BQ202 AQ N B Diode(ERC91-02) [D101]
26 0KY0D2Q0A0030 AL N B Diode(EC31QS03L) [D103]
27 0KY0D461A3800 AK N B Zener diode(HZ-36P) [D104]
28 0KYK7124AS2R5 AL N B Fuse [F1]
29 0KY0W000A0120 AC C Wire [F101]
30 0KY0W000A0050 AC C Wire(1/4W 0Ω) [F102]
31 0KY0H153A0020 AP B Integrated circuit(TA76431) [IC101]
32 0KY0W000A0150 AC C Wire [J1]
33 0KY0W000A0050 AC C Wire(1/4W 0Ω) [J2]
34 0KY0W000A0150 AC C Wire [J3]
35 0KY0W000A0070 AC B Wire [J101]
36 0KY0L110K2230 AS C Inductor(PLA10A) [L1]
37 0KYH7137AS001 AL N B Optical isolater [PC1]
38 0KY0T637A0010 AX B FET(2SK2662) [Q1]
39 0KY0T395A0020 AG B Transistor(2SC4097) [Q2]
40 0KYR3131AC225 AC N C Resistor(1/4W 2.2MΩ) [R1]
41 0KYR3120TC184 AB N C Resistor(1/8W 180KΩ) [R2]
42 0KYR3120TC184 AB N C Resistor(1/8W 180KΩ) [R3]
43 0KYR3120TC153 AB N C Resistor(1/8W 15KΩ) [R5]
44 0KYR3121TC681 AB N C Resistor(1/8W 680Ω) [R6]
45 0KYR3111VC333 AB N C Resistor(1/16W 33KΩ) [R8]
46 0KYR3111VC101 AB N C Resistor(1/16W 100Ω) [R9]
47 0KYR3111VC682 AB N C Resistor(1/16W 6.8KΩ) [R10]
48 0KYR3120TC133 AB N C Resistor(1/8W 13KΩ) [R11]
49 0KYR3111VC273 AB N C Resistor(1/16W 27KΩ) [R12]
50 0KYR3111VC102 AB N C Resistor(1/16W 1K) [R13]
51 0KYR3111VC681 AB N C Resistor(1/16W 6.8KΩ) [R17]
52 0KYR3121TC820 AB N C Resistor(1/8W 82Ω) [R19]
53 0KYR3131AC225 AC N C Resistor(1/4W 2.2MΩ) [R41]
54 0KYR3131AC103 AC N C Resistor(1/4W 10KΩ) [R101]
55 0KY0R153U5620 AC C Resistor(1/4W 5.6KΩ ±5%) [R103]
56 0KY0R153U5620 AC C Resistor(1/4W 5.6KΩ ±5%) [R104]
57 0KYR3131AC562 AC N C Resistor(1/4W 5.6KΩ ±5%) [R105]
58 0KYR3131AC562 AC N C Resistor(1/4W 5.6KΩ) [R106]
59 0KYR3131AC562 AC N C Resistor(1/4W 5.6KΩ) [R107]
60 0KYR3111VC101 AB N C Resistor(1/16W 5.6KΩ) [R110]
61 0KYR3121TC272 AB N C Resistor(1/8W 2.7KΩ) [R111]
62 0KYR3111VC821 AB N C Resistor(1/16W 820Ω) [R112]
63 0KYR3120TC272 AB N C Resistor(1/8W 2.7KΩ) [R113]
64 0KYR3114VC222 AC N C Resistor(1/16W 2.2KΩ) [R115]
65 0KYL2100DS007 AY N C Transformer [T1]
66 0KY0R854E1020 AG C Variable resistor(1/10W 1KΩ) [VR101]
67 0KY0D758A2410 AK B Transient voltage surge suppressor [Z1]
(Unit)
1 901 RDENT2188XHZZ BK N E Power supply PWB unit
[10] Operation panel PWB unit
(Unit)
901 DCEKP439CXH01 BG N E Operation panel PWB unit
[11] Ink PWB unit
1 RC-EZ3074XHZZ AG N C Capacitor(25WV 1000µF) [C1]
2 VCCCCY1HH181J AA C Capacitor(50WV 180PF) [C100]
3 VCCCCY1HH181J AA C Capacitor(50WV 180PF) [C101]
4 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C102]
5 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C104]
6 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C106]
7 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C107]
8 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C108]
9 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C111]
10 QCNWN335BXHZZ AL N C FFC,Ink 1 cable [CNHEAD1]
11 QCNWN335BXHZZ AL N C FFC,Ink 2 cable [CNHEAD2]
12 VHPGP1A38RBKL AZ N B Photo transistor [ENC1]
13 RH-IX2248XHZZ BF N B IC(IX2248) [IC100]
14 VRS-CZ1JB390J AA C Resistor(1/16W 39Ω ±5%) [R100]
15 VRS-CZ1JB390J AA C Resistor(1/16W 39Ω ±5%) [R101]
16 VRS-CZ1JB392J AD C Resistor(1/16W 3.9KΩ ±5%) [R102]
17 VRS-CZ1JB000J AA C Resistor(1/16W 0Ω ±5%) [R103]
18 VRS-CZ1JB392J AD C Resistor(1/16W 3.9KΩ ±5%) [R104]
19 VRS-CZ1JB392J AD C Resistor(1/16W 3.9KΩ ±5%) [R105]
