Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 12 –
[7] TEL/LIU PWB unit
46 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q102]
47 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q103]
48 VSRT1P141C+-1 AB B Transistor(RT1P141C) [Q104]
49 VRD-HT2HY223J AA C Resistor(1/2W 22KΩ ±5%) [R1]
50 VRD-HT2EY300J AA C Resistor(1/4W 30Ω ±5%) [R8]
51 VRS-RE3AA122J AC C Resistor(1W 1.2KΩ ±5%) [R10]
52 VRD-HT2EY910J AA C Resistor(1/4W 91Ω ±5%) [R11]
53 VRS-RE2HA101J AB C Resistor(1/2W 100Ω ±5%) [R12]
54 VRD-HT2HY202J AA C Resistor(1/2W 2KΩ ±5%) [R13]
55 VRD-HT2EY101J AA C Resistor(1/4W 100Ω ±5%) [R14]
56 VRD-HT2EY151J AA C Resistor(1/4W 150Ω ±5%) [R15]
57 VRS-TS2AD223J AA C Resistor(1/10W 22KΩ ±5%) [R101]
58 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ±5%) [R107]
59 VRS-CY1JB133J AA C Resistor(1/16W 13KΩ ±5%) [R108]
60 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R109]
61 VRS-CY1JB822J AA C Resistor(1/16W 8.2KΩ ±5%) [R111]
62 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R112]
63 VRS-CY1JB822J AA C Resistor(1/16W 8.2KΩ ±5%) [R114]
64 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ±5%) [R115]
65 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ±5%) [R116]
66 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R117]
67 VRS-CY1JB152J AA C Resistor(1/16W 1.5KΩ ±5%) [R119]
68 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R120]
69 VRS-CY1JB823J AD C Resistor(1/16W 82KΩ ±5%) [R121]
70 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R125]
71 VRS-CY1JB163J AA C Resistor(1/16W 16KΩ ±5%) [R126]
72 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R127]
73 VRS-CY1JB362J AA C Resistor(1/16W 3.6KΩ ±5%) [R128]
74 VRS-CY1JB621J AA C Resistor(1/16W 620Ω ±5%) [R129]
75 VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R131]
76 VRS-CY1JB822J AA C Resistor(1/16W 8.2KΩ ±5%) [R132]
77 VRS-CY1JB243J AA C Resistor(1/16W 24KΩ ±5%) [R133]
78 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R134]
79 VRS-CY1JB153J AA C Resistor(1/16W 15KΩ ±5%) [R135]
80 VRS-CY1JB332J AA C Resistor(1/16W 3.3KΩ ±5%) [R136]
81 VRS-CY1JB223J AA C Resistor(1/16W 22KΩ ±5%) [R137]
82 VRS-CY1JB393J AA C Resistor(1/16W 39KΩ ±5%) [R138]
1 83 RTRNI2164XHZZ AG B Transformer(I2164) [T1]
84 VHEHZ27-1//-1 AB B Zener diode(HZ27-1) [ZD2]
85 VHEHZ2A1///-1 AC B Zener diode(HZ2A1) [ZD5]
86 VHEHZ2A1///-1 AC B Zener diode(HZ2A1) [ZD6]
87 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD7]
88 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD8]
89 VHEHZ6A3///-1 AC B Zener diode(HZ6A3) [ZD9]
90 VHEHZ9C3///-1 AE B Zener diode(HZ9C3) [ZD11]
(Unit)
901 DCEKL434CXH01 BF N E TEL/LIU PWB unit
[8] Printer PWB unit
1 VCEAGA1HW107M AA C Capacitor(50WV 100µF) [C1]
2 VCEAGA1HW476M AB C Capacitor(50WV 47µF) [C2]
3 VCEAGA1HW107M AA C Capacitor(50WV 100µF) [C3]
4 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C4]
5 VCEAGA1EW227M AB C Capacitor(25WV 220µF) [C5]
6 VCEAGA1HW476M AB C Capacitor(50WV 47µF) [C6]
7 VCEAGA0JW227M AD C Capacitor(6.3WV 220µF) [C7]
8 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C24]
9 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C25]
10 VCCCCY1HH150J AB C Capacitor(50WV 15PF) [C102]
11 VCCCCY1HH150J AB C Capacitor(50WV 15PF) [C107]
12 VCCCCY1HH100D AA C Capacitor(50WV 10PF) [C114]
13 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C115]
14 VCKYCY1HB103K AA C Capacitor(50WV 0.01µF) [C116]
15 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C117]
16 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C118]
17 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C119]
18 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C120]
19 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C121]
20 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C122]
21 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C123]
22 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C124]
23 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C125]
24 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C127]
25 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C128]
26 VCKYCY1HB332K AA C Capacitor(50WV 3300PF) [C129]
27 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C131]
28 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C132]
29 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C133]
30 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C134]
31 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C136]
