NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 11 –
[6] Control PWB unit
240 VRS-CY1JB560J AA C Resistor(1/16W 56Ω ±5%) [R235]
241 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R236]
242 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R237]
243 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R238]
244 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R239]
245 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R241]
246 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R242]
247 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA1]
248 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA2]
249 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA3]
250 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA4]
251 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA5]
252 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA6]
253 RR-TZ3023SCZZ AC B Resistor array(100Ωx4) [RA7]
254 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA8]
255 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA9]
256 RR-TZ3016SCZZ AA B Resistor array(33Ωx4) [RA10]
257 RR-TZ3023SCZZ AC B Resistor array(100Ωx4) [RA11]
258 RR-TZ3023SCZZ AC B Resistor array(100Ωx4) [RA12]
259 RR-TZ3023SCZZ AC B Resistor array(100Ωx4) [RA13]
260 RR-TZ3017SCZZ AC B Resistor array(270Ωx4) [RA14]
261 RR-TZ3018SCZZ AC B Resistor array(470Ωx4) [RA15]
262 RR-TZ3018SCZZ AC B Resistor array(470Ωx4) [RA16]
263 RR-TZ3023SCZZ AC B Resistor array(100Ωx4) [RA17]
264 VHIPQ1X331M-1 AL N B IC,+3.3V REG(PQ1X331M2ZP) [REG3]
265 VHIPQ1X331M-1 AL N B IC,+3.3V REG(PQ1X331M2ZP) [REG4]
266 VHINJM78M24DL AM N B IC,24V Regulator(NJM78M24DL1A) [REG5]
267 RCRSP2190SCZZ AE B Crystal(32.256MHz) [X1]
268 RCRSB2185XHZZ AD B Crystal(32.768kHz) [X3]
269 VHE1N4744A/-1 AE N B Zener diode(1N4744A) [ZD1]
(Unit)
901 DCEKC984RXHZZ CE N E Control PWB unit(Within ROM) [UX-B700U]
DCEKC986RXHZZ CE N E Control PWB unit(Within ROM) [FO-B1600U]
[7] TEL/LIU PWB unit
1 VHVRA391PV6-1 AE B Varistor(RA-391P-V6-2) [AR1]
2 VHVRA501PC6-1 AG B Varistor(RA501P-C6) [AR2]
3 VHVRA501PC6-1 AG B Varistor(RA501P-C6) [AR3]
4 RC-FZ3024SCZZ AG C Capacitor(250WV 0.82µF) [C2]
5 VCKYPA1HB103K AA C Capacitor(50WV 0.01µF) [C5]
6 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C10]
7 VCEAGA1CW476M AB C Capacitor(16WV 47µF) [C11]
8 VCEAGA1HW107M AA C Capacitor(50WV 100µF) [C13]
9 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C14]
10 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C15]
11 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C17]
12 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C103]
13 VHD1SS355//-1 AB B Diode(1SS355) [C104]
14 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C105]
15 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C107]
16 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C108]
17 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C111]
18 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C112]
19 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C113]
20 VCKYTV1HF104Z AA C Capacitor(50WV 0.1µF) [C114]
21 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C116]
22 VCCCCY1HH330J AA C Capacitor(50WV 33PF) [C118]
23 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C123]
24 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C124]
25 VCKYCY1HB222K AA C Capacitor(50WV 2200PF) [C125]
26 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C127]
27 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [C129]
28 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C130]
29 VCKYTV1CF105Z AB C Capacitor(16WV 1µF) [C131]
30 VCCCCY1HH330J AA C Capacitor(50WV 33PF) [C132]
31 VCKYCY1HB821K AA C Capacitor(50WV 820PF) [C133]
32 RRLYD3436XHZZ AP B Relay(A5X-24E-908) [CML]
33 QJAKZ2079XH0D AD C Jack(4pin) [CNHJ]
34 QCNCM2548SC1B AH C Connector(12pin) [CNLIUA]
35 QJAKZ2060SC0B AD C Jack [CNLNJ]
36 QJAKZ2060SC0B AD C Jack [CNTLJ]
37 VHDDSS133//-1 AA B Diode(1SS133) [D1]
38 VHDDSS133//-1 AA B Diode(1SS133) [D2]
39 RH-IX2287SCZZ AG N B IC,Ope amp.(HA17324AFEL) [IC101]
40 RFILN2027XHZZ AC C Coil(R-5C) [L9]
41 VHPPC814X//-1 AE B Photo coupler(PC814X) [PC1]
42 VHPPC817X4/-1 AC B Photo coupler(PC817X4) [PC2]
1 43 VHPGP1S58V/-1 AE B Photo transistor(GP7S58VS) [PH1]
44 VSKTC3198GR-1 AD B Transistor(KTC3198GR) [Q2]
45 VSRT1N436C/-1 AD B Transistor(RT1N436C) [Q101]
To Next Page
