Sharp UX-B700 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 10 –
[6] Control PWB unit
160 VRS-CY1JB301J AA C Resistor(1/16W 300Ω ±5%) [R2]
161 VRS-RE3DA110J AE N C Resistor(2W 11Ω ±5%) [R3]
162 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ±5%) [R4]
163 VRS-CY1JB104J AA C Resistor(1/16W 100KΩ ±5%) [R5]
164 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R100]
165 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R101]
166 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R102]
167 VRS-CY1JB5R1J AC N C Resistor(1/16W 5.1Ω ±5%) [R103]
168 VRS-CY1JB512J AA C Resistor(1/16W 5.1KΩ ±5%) [R104]
169 VRS-CY1JB513J AA C Resistor(1/16W 51KΩ ±5%) [R105]
170 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R106]
171 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R107]
172 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R108]
173 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R115]
174 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R116]
175 VRS-CY1JB104J AA C Resistor(1/16W 100KΩ ±5%) [R117]
176 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ±5%) [R118]
177 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R120]
178 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R121]
179 VRS-CY1JB273J AA C Resistor(1/16W 27KΩ ±5%) [R127]
180 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R128]
181 VRS-CY1JB203J AA C Resistor(1/16W 20KΩ ±5%) [R130]
182 VRS-CY1JB124J AA C Resistor(1/16W 120KΩ ±5%) [R131]
183 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R133]
184 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R145]
185 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R146]
186 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R147]
187 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R148]
188 VRS-CY1JB392J AA C Resistor(1/16W 3.9KΩ ±5%) [R153]
189 VRS-CY1JB752J AA C Resistor(1/16W 7.5KΩ ±5%) [R154]
190 VRS-CY1JB105J AA C Resistor(1/16W 1MΩ ±5%) [R155]
191 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R156]
192 VRS-CY1JB330J AA C Resistor(1/16W 33Ω ±5%) [R162]
193 VRS-CY1JB330J AA C Resistor(1/16W 33Ω ±5%) [R163]
194 VRS-CY1JB330J AA C Resistor(1/16W 33Ω ±5%) [R164]
195 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R165]
196 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R166]
197 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R168]
198 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R169]
199 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R170]
200 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R171]
201 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R172]
202 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R173]
203 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R174]
204 VRS-CY1JB431J AC N C Resistor(1/16W 430Ω ±5%) [R175]
205 VRS-CY1JB105J AA C Resistor(1/16W 1MΩ ±5%) [R177]
206 VRS-CY1JB393J AA C Resistor(1/16W 39KΩ ±5%) [R178]
207 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R185]
208 VRS-CY1JB680J AA C Resistor(1/16W 68Ω ±5%) [R188]
209 VRS-CY1JB680J AA C Resistor(1/16W 68Ω ±5%) [R189]
210 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R190]
211 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R191]
212 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R192]
213 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R193]
214 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R198]
215 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R199]
216 RCILZ2179XHZZ AE N C Coil(BLM18HG102SNID) [R200]
217 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R205]
218 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R206]
219 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R207]
220 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R208]
221 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R209]
222 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R210]
223 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R211]
224 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R212]
225 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R213]
226 VRS-CY1JB680J AA C Resistor(1/16W 68Ω ±5%) [R214]
227 VRS-CY1JB106J AA C Resistor(1/16W 10MΩ ±5%) [R215]
228 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R216]
229 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R217]
230 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R218]
231 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R219]
232 VRS-CY1JB222J AA C Resistor(1/16W 2.2KΩ ±5%) [R220]
233 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ±5%) [R222]
234 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R223]
235 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R224]
236 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R225]
237 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R227]
238 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R228]
239 VRS-CY1JB562J AA C Resistor(1/16W 5.6KΩ ±5%) [R230]
