Sharp UX-B700

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-B700U
FO-B1600U
– 2 –
[1] Cabinet,etc.
1 DCEKC984RXHZZ CE N E Control PWB unit(Within ROM) [UX-B700U]
DCEKC986RXHZZ CE N E Control PWB unit(Within ROM) [FO-B1600U]
2 GCABB2419XHSA BB N D Bottom cabinet
3 CCNWN337BXH01 AL N C Speaker ass’y
4 CPLTM3258XH01 BA N E Drive unit
5 CROLP2499XH01 AM N E Exit roller ass’y
6 CROLR2362XH03 AQ N E Pick up roller ass’y
7 DCEKL434CXH01 BF N E TEL/LIU PWB unit
8 GCABA2418XHSA BC N D Upper cabinet
9 GCOVA2458XHSA AP N C Back cover
10 GCOVA2467XHSA AM N C Front cover
11 GLEGG2078XHZZ AD C Rubber leg
12 LBNDJ2006XHZZ AA C Band(100mm)
13 LBSHP2140XHZA AC C Back bearing,left
14 LBSHP2143XHZZ AC C Back bearing,right
15 LFRM-2240XHZZ AL N C Pick up hold frame
16 LPLTM2924XHFW AQ C Rotation plate
17 LPLTM3253XHZZ AS N C PWB installation plate
18 LPLTM3255XHZZ AP N C LIU upper plate
19 LPLTM3256XHZZ AR N C Power supply plate
20 LPLTM3259XHZZ AF N C Earth plate
21 LPLTP2884AXZA AP N C Separate plate
22 LPLTP3254XHZZ AE N C Panel stopper
23 LPLTP3258XHZZ AG N C Drive frame
24 LPLTP3260XHSA AP N C Exit tray
25 LPLTP3261XHSA AM N C Extension exit tray
26 LPLTP3263XHSA AM N C RP release plate
27 MLEVP2379XHZZ AE N C Front CV switch lever
28 MSPRC3390XHZZ AD N C Switch lever spring
29 MSPRC3391XHZZ AE N C CIS spring
30 MSPRC3406XHZZ AD N C Separate plate spring
31 MSPRC3407XHZZ AE N C Coil spring
32 MSPRP3055XHFJ AD C Speaker hold spring
33 MSPRP3119XHZZ AC C Panel lock spring
34 MSPRP3392XHZZ AK N C Earth spring
35 MSPRT2932XHFJ AC C RP release spring
36 NGERH2365AXZZ AD C RP release gear,left
37 NGERH2366AXZZ AD C RP release gear,right
38 NGERH2569XHZZ AC C Back gear
39 NGERH2570XHZZ AD C Reduction gear,21/38Z
40 NGERH2572XHZZ AD C Reduction gear,25/63Z
41 NGERH2580XHZZ AC C Reduction gear,15/22Z
42 NGERH2609XHZZ AE N C Reduction gear 2
43 NGERH2612XHZZ AE N C Document exit gear
45 NROLR2482XHZZ AR C Back roller
46 NSFTZ2367XHZZ AG N C Pick up shaft
47 PGIDM2617XHZZ AD C CIS holder,left
48 PGIDM2618XHZZ AD C CIS holder,right
49 PHOP-2095XHVA AR N C Paper hopper
50 PSEL-2015XHZZ AB C Paper pad
52 PSHEZ3293XHZZ AH C Separate plate pad
53 PSHEZ3344XHZZ AD C Separate sheet
54 PSHEZ3410XHZZ AB C Jack sheet
55 PSHEZ3750XHZZ AL N C Printer cable sheet
56 PSHEZ3759XHZZ AP N C Document under sheet
57 PSHEZ3760XHZZ AE N C Guide sheet,left
58 PSHEZ3761XHZZ AE N C Guide sheet,right
1 59 QACCD2054XHZZ AP B AC cord ass’y
60 QCNWN333BXHZZ AP N C CIS cable
61 QCNWN347BXHZZ AM N C Power supply cable
62 QCNWN354BXHZZ AY N C Printer cable
63 QCNWN389BXHZZ AF N C Earth cable
1 64 RCORF2124XHZZ AE B Core
1 65 RCORF2125XHZZ AE B Core(TRA31)
1 66 RDENT2188XHZZ BK N E Power supply PWB unit
67 RMOTS2182XHZZ AY N B Transmission motor
68 RUNTZ2118XHZZ BP N B CIS
69 TLABH491EXHZZ AE N C Ink change label
B1 LX-BZ2205XHZZ AC C Screw
B2 LX-BZ2222XHZZ AC C Screw(3x6)
B3 LX-BZ2241XHZZ AC C Screw(3x8)
B5 LX-BZ2282XHZZ AB C Screw(4x6)
B6 XBBSF30P06000 AA C Screw(3x6)
B7 XEBSD30P06000 AA C Screw(3x6)
B8 XEBSD30P10000 AA C Screw(3x10)
B9 XEBSE30P12000 AA C Screw(3x12)
B10 XHBSD30P06000 AA C Screw(3x6)
B11 XHBSD30P10000 AA C Screw(3x10)
B12 XHPSD30P08K00 AA C Screw(3x8)
W1 XWHSN40-08100 AA C Washer
