Replacing the Paper Roll
When a dye appears on the paper roll, it is time to replace the paper roll with new one. Be sure to
use the paper roll specified in “Specifications” section on page 32.
In case of journal printing
1. Set the mode switch to the REG position.
2. Remove the printer cover.
Caution:
The paper cutter is mounted on the printer cover.
Be careful not to cut yourself.
3. Press F to advance the paper by several lines and then cut it
to remove the take-up spool from the bearing.
4. After cutting the existing paper, remove the paper roll.
Then remove the remaining paper by pressing
F.
5. Make the straight part of the paper holding plate upward, and
push it up in the direction of the arrow to remove it as shown
in the second diagram. Then remove the paper roll from the
take-up spool.
6. Install a new paper roll and replace the take-up spool
according to the instructions on page 7.
In case of receipt printing, do the above steps 1, 2, 4
in this order and then install a new paper roll according
to the instructions on page 7.
