Shearwater Perdix - THE TOP ROW

Operations Manual Perdix
Manual DocRev B
13
TIME
220 22 130 1
DEPTH
TIME
STOP
in feet in meters
30 fpm / 9 mpm
50 fpm / 15 mpm
60+ fpm / 15+ mpm
TIME
220 22 130 1
DEPTH
TIME
STOP
69.7
DEPTH
The top row shows depth and time information
THE TOP ROW
Ascent Bar Graph
Shows how fast you are currently ascending.
Imperial: 1 arrow per 10 feet per minute (fpm) of ascent rate.
Metric: 1 arrow per 3 meters per minute (mpm) of ascent rate.
Imperial: In feet
(no decimal places).
Metric: In meters (displays with 1
decimal place up to 99.9m)
Depth
Note: If the depth shows a Flashing Red zero or shows at depth at the surface,
then the depth sensor needs service.
Note: Deco calculations assume 33fpm (10mpm) ascent rate.
when 1 to 3 arrows
Yellow when 4 to 5 arrows
Flashes Red when 6 arrows plus
