Shearwater Perdix - GAUGE MODE

Operations Manual Perdix
Manual DocRev B
39
Gauge - Surface Display
MAX
0
SURFACE
8:14
2 35
ft
hr
mn
AM
0
ft
AVG
0
ft
72F
Gauge - Dive Display
MAX
128
8:35
ft
AM
157
ft
AVG
74
ft
72F
21
:16
Stopwatch Running
MAX
STOPWATCH
128
8:35
ft
AM
157
ft
AVG
74
ft
72F
21
:16
2:56
Stopwatch Stopped
MAX
STOPWATCH
128
8:35
ft
AM
157
ft
AVG
74
ft
72F
21
:16
2:56
GAUGE MODE
Gauge Mode turns the Perdix into a simple depth and time display
(a.k.a. a bottom timer).
Change to Gauge Mode in the System Setup Mode Setup menu.
Since decompression tissues are not tracked in Gauge Mode,
changing to or from Gauge Mode resets the deco tissues.
Features:
Extra-Large Depth Display (in feet or meters)
Extra-Large Time Display (in minutes:seconds)
Maximum and Average Depth on main screen.
Stopwatch
Resettable Average Depth
The Gauge display is organized as:
Depths along the left.
Times along the right.
Most important information (Depth, Dive Time) on the top row.
STOPWATCH
When diving, starting or stopping the Stopwatch is the first
menu option.
When stopped, the word “Stopwatch” displays in red.
When non-zero, the stopwatch can be reset. Reset behavior
depends on state:
If running when reset, it continues running, counting up again
from 0.
If stopped when reset, then it is set 0 and remains stopped.
RESETTABLE AVERAGE DEPTH
During a dive, the average depth can be reset.
While on the surface, the MAX and AVG values display the
maximum and average depth of the last dive. The AVG depth
displayed on the surface is for the entire dive, regardless of
whether the reset average depth option was used. The dive log
also records the average depth for the entire dive.
