Operations Manual Perdix
Manual DocRev B
96
STORAGE AND MAINTENANCE
The Perdix dive computer should be stored dry and clean, and
without batteries installed.
Do not allow salt deposits to build up on your dive computer.
Wash your computer with fresh water to remove salt and other
contaminants. Do not use detergents or other cleaning chemicals
as they may damage the Perdix dive computer. Allow to dry
naturally before storing.
Do not wash under high pressure jets of water as it may cause
damage to the depth sensor.
Store the Perdix dive computer out of direct sunlight in a cool, dry
and dust free environment. Avoid continuous exposure to direct
ultra-violet radiation and radiant heat.
Servicing
There are no user serviceable parts inside the Perdix.
Do not tighten or remove the faceplate screws.
Clean with water ONLY. Any solvents may damage the
dive computer.
Service of the Perdix may only be done at Shearwater Research,
or by any of our authorized service centers.
Your nearest service center can be found at
www.shearwater.com/contact
Specification Perdix Model
Operating Modes OC Tec
OC Rec
OC/CC (internal PPO2)
Gauge
Decompression Model Bühlmann ZHL-16C with GF
VPM-B and VPM-B/GFS (optional)
Display Full color 2.2" QVGA LCD
with always on LED backlight
Pressure (depth) sensor Piezo-resistive
Calibrated Range 0 Bar to 14 Bar
Accuracy +/-20 mBar (at surface)
+/-100 mBar (at 14bar)
Crush Depth Limit 27 Bar (~260msw)
Surface Pressure Range 500 mBar to 1040 mBar
Depth of dive start 1.6 m of sea water
Depth of dive end 0.9 m of sea water
Operating Temperature Range +4ºC to +32ºC
Short-Term (hours) Temperature
Range
-10ºC to +50ºC
Long-Term Storage Temperature
Range
+5ºC to +20ºC
Battery AA Size, 0.9V to 4.3V
User replaceable
Battery Operating Life
(Display Medium Brightness)
45 Hours (AA 1.5V Alkaline)
130 Hours (SAFT LS14500)
Communications Bluetooth Smary Ready
Compass Resolution 1°
Compass Accuracy ±5°
Compass Tilt Compensation Yes, over ±45° pitch and roll
Dive Log Capacity Appoximately 1000 hours
Battery cap o-ring Dual o-rings. Size: AS568-112
Material: Nitrile Durometer: 70A
Wrist Attachment 2 x 3/4" Elastic Straps with Buckles, or
2 x Bungee Cord (3/16" diameter cord)
Weight 152 g
Size (W X L X H) 81mm X 71mm X 38mm
