The Perdix model contains a tilt-compensated digital compass.
Compass features:
1° resolution
±5° accuracy
Smooth, high-speed refresh rate
User set heading marker with reciprocal
True North (declination) adjustment
Tilt compensation ±45°
Viewing the Compass
When enabled, the compass is viewed by pressing the SELECT
(right) button once. Press SELECT again to continue on to view the
regular info screens.
Unlike the regular info screens, the compass never times out
back to the main screen. Pressing the MENU (left) button brings
up the Mark Heading option. Pressing MENU again returns to the
main screen.
TIME
NE
N
24
1.30 1.30 1.29
22.1 3
DEPTH
TIME
STOP
COMPASS
Watch the video:
Compass Features
A video demonstration of compass operation on the Petrel 2 dive computer can
be found below. (operation is the same for Perdix):
