Shelly Wave 1PM User Manual

EN.
30
14. Technical Specifications
Power supply
110-240 V AC / 24–30 V DC
Power consumption
< 0.3 W
Power measurement (W)
Yes
Max switching voltage AC
240 V
Max switching current AC
16 A
Max switching voltage DC
30 V
Max switching current DC
10 A
Overheating protection
Yes
Overload protection
Yes
Distance
Up to 40 m indoors (131 ft.)
(depends on local condition)
Z-Wave™ repeater:
Yes
CPU
Z-Wave™ S800
Z-Wave™ frequency bands:
868,4 MHz; 865,2 MHz; 869,0
MHz; 921,4 MHz; 908,4 MHz;
916 MHz; 919,8 MHz; 922,5
MHz; 919,7-921,7-923,7 MHz;
868,1 MHz; 920,9 MHz
Maximum radio frequency
power transmitted in
frequency band(s)
< 25 mW
Size (H x W x D)
37x42x16 ±0.5 mm /
1.46x1.65x0.63 ±0.02 in
Weight
27 g / 0.95 oz.
Mounting
Wall console
Screw terminals max. torque
0.4 Nm / 3.5 lbin
Conductor cross section
0.5 to 1.5 mm² / 20 to 16 AWG
Conductor stripped length
5 to 6 mm / 0.20 to 0.24 in
Shell material
Plastic
