ENGLISH
19
ENGLISH
• The volume level of each channel can be adjusted easily with the test tone function.
Note : When the SPEAKER button is set to off, the test tone function does not work.
Adjusting each channel level with test tone
• The test tone mode is displayed and will be heard
from the speaker of each channel for 2 seconds as
follows:
FL C FR SR
Front Left Center Front Right Surround Right
SW SL
Subwoofer Surround Left
• When the speaker setting is "N (None or No)", the
test tone of the corresponding channel is not
available.
1. Enter the test tone mode.
2. At each channel, adjust the level as
desired until the sound level of each
speaker is heard to be equally loud.
3. Cancel the test tone function.
• You can select the desired channel with pressing
the CONTROL UP()/DOWN() buttons or the
CURSOR UP()/DOWN() buttons
When selecting the "PANO (Panorama)" mode
This mode extends the front stereo image to include the surround speakers for an exciting "wraparound" effect
with side wall imaging. Select "OFF" or "ON"(default value: OFF).
When selecting the "C. WIDTH (Center width)" control
This adjusts the center image so it may be heard only from the center speaker, only from the left/right speakers
as a phantom image, or from all three front speakers to varying degrees.
The control can be set in 8 steps from 0 to 7(default value : 3).
When selecting the "DIMEN (Dimension)" control
This gradually adjusts the soundfield either towards the front or towards the rear. The control can be set in 7
steps from -3 to +3 (default value : 0).
4. Repeat the above steps 2 and 3 to adjust other parameters.
Continued
To Next Page
