209
11-2 Specifications
Model EM60 SD
Lifting link 2-point link
Adjustment of mowing height Gauge wheel
Mowing width (mm) 1520
Mowing height (mm) 38 – 115 {7 steps}
Mowing blade speed (rpm) 2899
Mowing blade end speed (m/sec.) 79
No. of mowing blades 3
Standard mowing blade dimensions (T × W × L, mm) 7 × 50 × 518
Gear oil (ℓ) 0.6
Total weight (kg) 175
Applicable models CM284·364
Power flow
1102X
