1-1 Specifications & Performances
Model
CM284 CM364
Engine
Model J843 N843L
Type Water-Cooled 4-Cycle Vertical Diesel Engine
Number of Cylinders 3
Total Stroke Volume 1330 cc 1662 cc
Maximum Output 20.8 kW (28 HP)/2700 rpm 26 kW (35 PS)/2700 rpm
Compression Ratio 22.5 : 1
Fuel Diesel Fuel Oil
Starting Method By Starting Motor
Maine Body
Overall Length 2415 mm
Overall Height 1390 mm
Overall Width 1220 mm (narrow), 1370 mm (wide)
Weight 730 kg 750 kg
Tire
Front Wheel
23
×
10.5 – 12
Rear Wheel
20 × 8.00 – 10
No. of Running Speeds 2 Forward Speeds, 2 Reverse Speeds (Continuously variable speed)
Transmission System L/H Switching, All Hydraulic Continuously Variable Speed (HST)
Brake Wet Disc Brake
Lift Control Valve Relief Set Pressure 9.8 MPa {100 kgf/cm
2
}
Relief Set Pressure/ Steering 5.88 – 6.56 MPa {60 – 67 kgf/cm
2
}/ Full Hydraulic Power Steering
Running Speed
Forward: L 0 – 10.0 km/h
Forward: H 0 – 17.2 km/h
Reverse: L 60 – 70 % of Forward Speed
Reverse: H 60 – 70 % of Forward Speed
Capacity
Fuel Tank 50.5 ℓ
Engine Oil 4.6 ℓ (Including oil filter) 5.6 ℓ (Including oil filter)
Transmission Gear Oil Front 20 ℓ, Rear 2.3 ℓ
Cooling Water 5.1 ℓ 5.3 ℓ
Electric Units
Battery 75 D 26 L
Starting Motor 12 V – 1.7 kW 12 V – 2.0 kW
Alternator 12 V – 40 A
Head Light 23 W
Monitor Lamp 3 W
Dash Panel Lamp 2 W
Light Switch Lamp 1.4 W
