Part Inspection Item
Standard
Dimensions
Standard
Assembling Vlue
Repair Vlue
Service
Limit
Remarks
Injection nozzle
Type (Nozzle) 105007 - 1170 (NP-DN4PDN117) BOSCH
Injection pressure MPa {kgf/cm
2
}
15.20 – 16.18
{155 – 165}
Injection angle
4°
Nozzle and holder tightening torque
N·m {kgf·m}
58.8 – 68.6
{6 – 7}
Cooling conditions
Cooling water amount (ℓ) 5.3
Reserve tank
0.6 ℓ
Thermostat operating temperature
(°C)
82 80 – 84
Thermostat full open temperature
(°C)
95
V belt (fan) looseness (load at center
49 N {5 kgf })
5
Dimension A
36.5
Start to open pressure of radiator cap
pressure valve kPa{kgf/cm
2
}
73.5 {0.75} 88.2 {0.9}
Start to open pressure of radiator cap
negative pressure valve
kPa{kgf/cm
2
}
4.9 {0.05}
Less than
4.9 {0.05}
Starting motor
Model RA(228000 – 5121)
No. of teeth of pinion gear 9
Pinion gear shifting method Magnetic shifting
Wear of commutator dia.
φ35.0
φ34.0
Brush length 15 12
Alternator
Type A007T03877 12 V – 40 A
Slip
ring
Diameter
φ22.7
22.1
Surface condition
Correct with cloth file if
stained or damaged
Brush length 18.5 5
Brush spring pressure N (gf)
4.6 – 5.8
{470 – 590}
2.6 {270}
