2.2.4 Parts List (SAL-3.5HP/5HP-UGP)
Table 2-2：Parts List (SAL-3.5HP/5HP-UGP)
No.
Name Part No. No.
Name Part No.
1 Anti-vibration pad Ф50 YW03005000000
21 Filter barrel roll BL19003500120
2 Flat washer 8 YW66082200100
22 Filter barrel assembly -
3 Nut M12 YW64012100000
23 6-hole acryl YR40001200000
4 Base BL21003500120
24
6-hole sight glass
fastene
YR40000600000
5 Air inlet pipe BL26003506520-
25
Iron sheet of 6-hole sight
glass
YW09000600000
6 Blower flange - 26 Butterfly nut 5/16″ YW09051600000
7
Vacuum breaking
diaphragm valve 1.5″
BY20015000050
27 Flat washer YW66082200100
8
Vacuum breaking
diaphragm valve piping
BL21003500420
28 Strainer fixing plate 8 BL21003500520
9
Lower welded block of
stand column
- 29 Air filter ADC2 YR50181100000
10
Right stand column BL26003506620
30 Air suction pipe -
11
Upper welded block of
stand column
- 31 Coupling clip YW07000200000
12
Snap hook* YW02003000400
32 Filter barrel lid assembly
-
High pressure blower
3.5HP
BM30053500050
33 Alarm light YE83305100200
High pressure blower
5HP
BM30055000050
34 Control base board -
13
High pressure blower
5HP (two-stage)
YM30433700000
35 Cover board -
14
Dust collection bin BL26003507021
36 Main power switch YE10210300000
15
4-hole acryl BH32070000050
37 Controller holder BL26010241820
16
4-hole sight glass
fastener
YR40000400000
38 Control box BL26003505321
17
Iron sheet of 4-hole
sight glass
YW09000000400
39
Line jig fixing plate
Insulation material
-
18
Pipe bundle 2.5″ YW02002500000
40 Filter barrel support -
19
Steel wired plastic Pipe
2”
YR60205000100
41
Control cabinet mounting
plate
-
20
Dust collecting barrel
fastener*
YR10708000100
42 Left stand column BL26003506620
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
To Next Page
