Shini SAL-UGP Series User Manual

23(61)
2.2.6 Parts List (SAL-7.5HP/10HP/15HP-UG)
Table 2-3：Parts List (SAL-7.5HP/10HP-UG)
No. Name Part No. No. Name Part No.
1 Hex. head screw YW60084000200 20 Clip YW02002500000
2 Spring washer YW66081600000 21 Steel wire hose YR60002500000
3” movable castor YW03000300200 22 Filter barrel assembly -
3
3” castor with brake YW03000300000 23 Butterfly nut YW69051600000
4 Base BL26007502721 24 Filter fixing plate BL26007504720
High pressure blower
7.5HP
BM30075000050 25 Air filter* YR50221400000
High pressure blower
7.5HP single-stage
YM30635500000 26 Spring clip* YW02003000400
High pressure blower
10HP
BM30081000050 27 Filter barrel lid assembly -
5
High pressure blower
10HP single-stage
YM30637500000 28 2.5” coupling clip YW07002500600
6 Blower flange - 29 Filter barrel lid assembly -
7 Air inlet fastener BL26007504920 30 Alarm light YE83305100200
8
Pneumatic diaphragm
valve
BY20020000150 31 Main switch YE10210300000
9
Pneumatic valve
coupling
BL26007502020 32 Controller holder BL26010241820
10 Castor YW03002500000 33 Control cabinet BL26007503521
11 Dust collecting barrel BL26007502421 34
Control cabinet mounting
plate
-
12 Aluminium handle BW20012000040 35
Iron sheet of 4-hole sight
glass
YW09000000400
13
Dust collecting barrel
seal ring*
- 36 Acryl BH32070000050
14 Large handle YW02003000100 37
4-holes window seal
ring
YR40000400000
15 Cyclone baffle - 38 Middle board -
16
Bottom ring of filter
barrel
- 39 Supporting frame 1 -
17
6-holes window seal
ring
YR40000600000 40 Pillar of filter barrel -
18 Acryl YR40001200000 41 Filter fixing bracket -
19
Iron sheet of 6-hole
sight glass
YW09000600000
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
