Shini SAL-UGP Series User Manual

12(61)
Table 1-1：The Installation Dimension of Hopper
Model D1(mm) D2(mm) D3(mm) D4(mm) D5(mm)
SHR-P-12U
Ф197 Ф254.5 Ф275 Ф231.5 Ф9
SHR-P-30U
Ф377 Ф413 Ф430 - Ф7
SHR-P-30U-1
Ф377 Ф413 Ф430 - Ф7
SHR-P-30U-2
Ф377 Ф413 Ф430 - Ф7
SHR-P-60U
Ф437 Ф470 Ф490 - Ф7
SHR-P-60U-3
Ф437 Ф470 Ф490 - Ф7
SHR-P-90U
Ф547 Ф583 Ф600 - Ф7
SHR-P-90U-5
Ф547 Ф583 Ф600 - Ф7
1.3.4 Specifications
Table 1-2：Specifications
For Conveying Raw Material Contains 30% Powder (BAG FILTERS are fitted to
the powder receiver)
Main Unit Powder Receiver Dimensions (mm)
Model
Motor
Power
(kW)
(50/60Hz)
Specifi-
cation
Applied to
Conveying
Pipe Dia.
Air
Suction
Pipe
Dia.
Hopper
Capacity
(L)
Hopper
Dia.
(mm)
Conveying
Capacity
(kg / hr)
Filter
Cloth
Quantity
(Main Unit)
H×W×D
(Receiver)
H×W×D
SAL-1HP-UGP
0.75 /
0.85
SHR-P-12U 12L Φ270 300 3 940×535×380
SAL-2HP-UGP 1.5 / 1.8 SHR-P-30U
1.5” 1.5”
30L Φ380 400 7
1000×400×500
1325×730×470
SAL-3.5HP-UGP 2.4 / 2.6 800
SAL-5HP-UGP
1380×490×590
SAL-5HP-UGP-D
3.7 / 4.2
SHR-P-60U 2” 2” 60L Φ440
1200
10
1380×690×590
1500×780×500
SAL-7.5HP-UGP 1830×585×675
SAL-7.5HP-UGP-D
5.5 / 6.3 1500
1830×740×675
SAL-10HP-UGP 1830×585×675
SAL-10HP-UGP-D
7.5 / 8.6
3Φ
SHR-P-90U 2.5” 2.5” 90L Φ550
2000
19
1830×740×675
1640×890×635
