8(61)
1.1 Coding Principle
S
AL -
xxHP-
UG
xx
UG: European Type
and Separating
Shini Auto Loaders
Motor Power (HP)
Option
*
Note:
*
D
=Double-stage Blower
P=Powder Loader
CE=CE Conformity
A
=Add Air Accumulator
1.2 Feature
1) Standard configuration
Data backed up on EPROM in case of power failure and does not require
back up battery.
It consists of a cyclone dust separator and a dust collective bin to effectively
reduce the load of filter.
Function for setting regrind mix ratio via optional SPV-U.
Standardly equipped with warning lamp as the alarm device.
Based on customer's requirements, there are two types of filters: bag and
plate, for 30% and 100% powder conveying respectively. The air
accumulator and self-cleaning device are standard equipment for hopper.
2) Accessory option
In the case of much impurity or recycled materials included in raw materials,
main unit can be equipped with air accumulator auto washing unit as options,
and add "A" at the model behind. (Suitable for SAL-3.5HP-UG and models
above)
Optionally provide multi-functional installation frame HMB-900 with 900 mm
largest dia.adjusting range for selection.
Provide both standard and optional heat-insulative Euro collective hopper
SCH-6U/12U/24U for selection (Except for SAL-UGP series, which will use
special collective hopper).
Optional cyclone dust separator is available for SAL-1HP/2HP-UG.
Buzzer available as an option.
