2.2.8 Parts List of Storage Hopper with Plate Filter
Table 2-4：Parts List of Storage Hopper with Plate Filter
No. Name Part No. No. Name Part No.
1
Fastener for filtering
barrel
YR10010000200 21 Filter cloth YP82050000000
2 Cruciform slot screw YW63063000000 22 Filter barrel body -
3 Magnet cover BL21000600120 23
Fixing plate of suction
pipe
-
4 Permanent magnet YW90213700000 24
Fastener of the suction
pipe
-
5 Magnet cover BH12000600010 25 Suction pipe -
6 Press block - 26 Non-return flap BL27002400920
7 Flat washer YR40000400000 27 Non-return valve -
8 Lockup nut YW64000600200 28 Mounting bracket YE30004200000
9
Connecting block for
discharging plate
BL27006000020 29
Pressure regulating
valves
YE30421400000
10 Discharging plate BL27006001120 30 Cruciform slot screw YW63064000000
11 The cover of sensor - 31 Plate filter YR50450500000
12 Control box - 32 Flange for the filter -
13 Ball valve 3/8” YW50030800100 33
Square aluminum
handle
BW20012000040
14 Air accumulator BL27006000120 34 Filter barrel lid fastener -
15
Fixing flange of the air
accumulator
- 35
Big handle in new
design
-
16 Air pipe coupling YW80161200000 36 Diaphragm valve YE30020000100
17 Air pipe YR60161000000 37 Filter barrel lid -
18 Copper connector - 38
vacuum separating
valve
BY20500000050
19 Spring clip** YW02003000400 39 Air suction port coupling BL27006001620
20 Air vent window BL27006001320
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
