Shini SAL-UGP Series User Manual

41(61)
Table 2-13：Electrical Components List (SAL-2HP-UGP) (230V)
SAL-2HP-UGP
NO. Symbol Name
Specification Part NO.
1 Q1 Main switch* 16A YE10200300000
2 Q2 Circuit breakers* 20A YE40602000000
3 K1 Contactors** 230V 50/60Hz YE00310000000
4 F1 Overload relays 5~8A YE01050800000
5 F2 F3 Fuse** 250V 2A YE41001000000
6 S1 Control switch 4P (WH) YE10210400000
7 H1 Buzzer 60-250VAC 50/60Hz YE84003500000
8 H2 Alarm lamp 230VAC 50/60Hz YE83305100200
9 A1
Microomputer
mainboard**
230VAC 50/60Hz -
10 A2 Keypad** - -
11 X1
Heavy duty
connectors
16A 400V YE68061640100
12 X2 Terminal board 2.5mm
2
YE61250040000
13 - Terminal board 2.5mm
2
PE YE61253500000
14 - Terminal board 2.5mm
2
YE61250040000
15 - Terminal board 2.5mm
2
PE YE61253500000
16 X3 Waterproof linker 250V 3P YE62163000100
17 M Blower** 2HP -
18 Y1 Solenoid vavle* 230V 50/60Hz YE32051800300
19 Y2 Solenoid vavle* 230V 50/60Hz YE32212000000
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
