EQ Contour
Use the builtin equalizer contour to quickly apply EQ changes to all channels. The EQ contour is separate from the perchan
nel EQ settings. Applying both the EQ contour and per-channel EQ has a cumulative effect, meaning that the EQ changes
stack on top of each other.
To use, open the microphone in Designer and click EQ contour to turn it on or off.
MXA710 EQ contour: Low shelf at 300 Hz, -6 dB
Click Bypass all EQ to quickly bypass any EQ contours or channel EQ settings.
Best Practices
Listen to and test your system as you make EQ changes, and make sure they work for your specific room.
When using with a P300 audio conferencing processor, turn off the microphone's channel EQ and EQ contours. Use the
P300 to make EQ adjustments.
Automix
Automix Channel
This channel automatically mixes the audio from all selected channels to a single output. To adjust the automix channel set
tings, go to:
MXA710, MXA910, MXA920:[Your device] > IntelliMix > Properties
P300 and IntelliMix Room:[Your device] > Automixer > Properties
All IntelliMix DSP blocks can be applied to the automix channel.
To use the automix channel, do the following:
Check that Send to mix is automatically selected (blue) for all channels. To exclude channels from the automix channel
and treat them as individual direct outputs, deselect Send to mix (gray).
Route the automix channel in Designer or Dante Controller.
Automix Settings
Use these settings to adjust the automixer. Designer adjusts these settings automatically if you use the auto route feature, but
you can customize to fit your installation. To adjust, go to:
MXA710, MXA910, MXA920:[Your device] > IntelliMix > Properties
P300 and IntelliMix Room:[Your device] > Automixer > Properties
™
