SICK C4-RD

Protective field
hei
ght in mm
Typical power consumption of
sender in W
Typical power consumption of
receiver in W
1)
Resolution
14 mm
Resolution
30 mm
Resolution
14 mm
Resolution
30 mm
500 1.12 0.88 2.24 1.76
550 1.16 0.90 2.32 1.79
600 1.20 0.91 2.40 1.82
750 1.32 0.96 2.64 1.92
900 1.44 1.01 2.88 2.02
1050 1.56 1.06 3.12 2.11
1200 1.68 1.10 3.36 2.21
1350 1.80 1.15 3.60 2.30
1500 1.92 1.20 3.84 2.40
1)
Power discharged again via the OSSDs depending on the connected OSSD load must be added to the
t
able values.
12.4 Length of cable
Table 17: Maximum lengths of cable for wire cross-section 0.34 mm
2
, c
opper wire
Single system
Separate connecting cables for
sender and r
eceiver
r
s
b c
S
r
s
b ≤ 85 m c ≤ 15 m
Connection of sender and receiver
v
ia T-connector on the sender
r
s
a
T
c
S
r
s
a + c ≤ 15 m
Connection of sender and receiver
v
ia T-connector on the receiver
r
s
a
T
b
S
r
s
a ≤ 15 m b ≤ 85 m
S Control cabinet with safety relay or safety controller
T T-connector
12.5 Table of weights
Table 18: Weight of sender and receiver
Protective field height in mm Weight in g
1)
s S
ender r Receiver
150 145 147
200 189 191
250 234 236
300 278 280
12 TECHNICAL DATA
