SICK C4-RD User Manual

13 Ordering information
13.1 Scope of delivery
Scope of delivery, sender
•
S
ender
Scope of delivery, receiver
•
R
eceiver
•
Test rod with diameter corresponding to the resolution of the safety light curtain
•
Safety note
•
Mounting instructions
•
Operating instructions for download: www.sick.com
13.2 Ordering information
Table 20: Ordering information C4-RD for 14 mm resolution
Protective field
hei
ght in mm
s S
ender r Receiver
Part number Type code Part number Type code
150 1112986 C4C-SC01510A10000 1112993 C4C-EC01510A10000
200 1112987 C4C-SC02010A10000 1112994 C4C-EC02010A10000
250 1112988 C4C-SC02510A10000 1112995 C4C-EC02510A10000
300 1113196 C4C-SC03010A10000 1113205 C4C-EC03010A10000
350 1112989 C4C-SC03510A10000 1113206 C4C-EC03510A10000
400 1112990 C4C-SC04010A10000 1113207 C4C-EC04010A10000
450 1113197 C4C-SC04510A10000 1113208 C4C-EC04510A10000
500 1112991 C4C-SC05010A10000 1113209 C4C-EC05010A10000
550 1112992 C4C-SC05510A10000 1113210 C4C-EC05510A10000
600 1113198 C4C-SC06010A10000 1113211 C4C-EC06010A10000
750 1113199 C4C-SC07510A10000 1113212 C4C-EC07510A10000
900 1113200 C4C-SC09010A10000 1113213 C4C-EC09010A10000
1050 1113201 C4C-SC10510A10000 1113214 C4C-EC10510A10000
1200 1113202 C4C-SC12010A10000 1113215 C4C-EC12010A10000
1350 On request C4C-SC13510A10000 On request C4C-EC13510A10000
1500 On request C4C-SC15010A10000 On request C4C-EC15010A10000
Table 21: Ordering information C4-RD for 30 mm resolution
Protective field
height in mm
s S
ender r Receiver
Part number Type code Part number Type code
150 1113218 C4C-SC01530A10000 1113227 C4C-EC01530A10000
200 1113219 C4C-SC02030A10000 1113228 C4C-EC02030A10000
250 1113224 C4C-SC02530A10000 1113233 C4C-EC02530A10000
300 1113225 C4C-SC03030A10000 1113234 C4C-EC03030A10000
350 1113226 C4C-SC03530A10000 1113235 C4C-EC03530A10000
400 1113231 C4C-SC04030A10000 1113246 C4C-EC04030A10000
450 1113232 C4C-SC04530A10000 1113247 C4C-EC04530A10000
500 1113239 C4C-SC05030A10000 1113248 C4C-EC05030A10000
550 1113240 C4C-SC05530A10000 1113249 C4C-EC05530A10000
600 1113241 C4C-SC06030A10000 1113238 C4C-EC06030A10000
750 1113242 C4C-SC07530A10000 1113237 C4C-EC07530A10000
ORDERING INFORMATION 13
8025644/19Z2/2021-03-09 | SICK O P E R A T I N G I N S T R U C T I O N S | C4-RD
67
Subject to change without notice
