Chapter 6 Operating Instructions
CLV 42x bar code scanner
6-10 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 981/O078/16-08-2004
Operation
Function of the CAN interface (alternative):
See Operating Instructions "Application of the CAN Interface" (no. 8 009 180, English
version)
Data Connection to the CMF 400 Fieldbus gateway:
• Choose the fieldbus system for each communication port FIELDBUS GATEWAY tab
HOST GATEWAY section and/or AUXILIARY GATEWAY section
• Communication parameters for the selected fieldbus system FIELDBUS GATEWAY tab
Data output string of host/CAN interface:
• Select contents of the “Header“, “Code Info/Separator“, “Splitter“ and “Terminator“
blocks
DATA STRINGS tab OUTPUT FORMAT section
• Position of the „Code Info/Separator“ block in data output string DATA STRINGS tab
CODE INFO/SEPARATOR section
• Set no read format DATA STRINGS tab READING DATA IN CASE OF ERROR section and
ERROR STRING section
• If necessary, parameterize/activate test string DATA STRINGS tab EXTERNAL DATA
S
TRING PARAMETERS section
• If necessary, parameterize the integration of an external data string into the reading
result
DATA STRINGS tab TEST STRING section
• Parameterize special functions DATA STRINGS tab SPECIALS button
f) Parameterizing auxiliary interface
• AUXILIARY INTERFACE tab
6.4.4 Configuring the CLV with AutoSetup
AutoSetup enables the reading and code configurations of the CLV to be adapted automat-
ically to the application at hand. The following conditions must be fulfilled with regard to this:
• one bar code (code type, code length)
• fixed reading distance
• conveyor belt off (static reading)
The CLV determines the code type, code length and the most favorable scanning rate for
the bar code presented. This takes place in Free Running mode. Once AutoSetup has been
completed successfully, the CLV copies the parameter values determined to its parameter
set.
All other code types and code lengths are then disabled. If AutoSetup was not
completed successfully, the parameter set is not changed. The CLV does not read a
Pharmacode or any EAN/UPC types in AutoSetup. It does not respond to an external reading
pulse.
AutoSetup can be activated in three different ways in the CLV:
• via the user interface of CLV Setup
• by presenting profile bar code no. 10 (on the card supplied) to the optical interface
(reading window).
See Chapter 10.5.1 Activating AutoSetup with a profile bar code,
Page 10-17.
• via a command string (via the serial interface). See Chapter 10.6 Configuring the CLV
with command strings, Page 10-22.
While AutoSetup is running, the CLV outputs the step-by-step changes made to the
parameter values in the search mode and the determined diagnosis data via the terminal
