Operating Instructions Chapter 6
CLV 42x bar code scanner
Operation
8 009 981/O078/16-08-2004 © SICK AG · Division Auto Ident · Germany · All rights reserved 6-7
• Type of logical data network of connected CLVs
• Use of switching inputs/outputs of the CLV as CANopen Digital I/O
Fieldbus Gateway
This tab (and additional dialog boxes) are used to set the following:
• Data interface of the CLV to be connected to the gateway in the CDM 420
• Type of fieldbus
• Special fieldbus parameters
Extras
This tab is used to edit parameters that were not recognized by CLV Setup after an upload.
Note The online "CLV Setup Help" contains a detailed description of the functions of the
parameters and their valid entries. S
ee Chapter 10.4.8 Online help – CLV Setup Help,
Page 10-14.
6.4.3 Parameterization guide
Overview of parameterization procedure
• Parameterize optical reading characteristics of the scanner
• Set up reading pulse
• Parameterize the evaluation characteristics of the decoder
• Parameterize output characteristics (data, result status)
• Define the function of the terminal interface
When the CLV is started up for the first time, the factory default settings are in effect. The
following parameters must then be set:
a) Parameterizing optical reading characteristics
• Scanning frequency READING CONFIGURATION tab READING PARAMETERS section
• Min. reading distance READING CONFIGURATION tab MINIMUM DISTANCE section
• Quiet zone READING CONFIGURATION tab QUIET ZONE section
• Poor quality bar code print READING CONFIGURATION tab CODELABEL QUALITY section.
Alternative: Enable Dynamic Reading Configuration READING CONFIGURATION tab
DYNAMIC READING CONFIGURATION ACTIVE
• Limite evaluation range of scan line READING CONFIGURATION tab CODE POSITION
section
