Chapter 6 Operating Instructions
CLV 42x bar code scanner
6-14 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 981/O078/16-08-2004
Operation
6.5 Operating modes and outputting the reading result
The following CLV operating modes/functions can be selected in CLV Setup:
Standard operating mode
• Reading mode
For startup
• Percentage evaluation
• Adjusting mode
For adapting device to application
• AutoSetup (automatic adaptation to reading conditions):
See Chapter 6.4.4 Configuring the CLV with AutoSetup, Page 6-10.
• Profile programming (configuration):
See Chapter 10.5.2 Profile programming, Page 10-19.
• Parameterization (configuration):
See Chapter 6.4.1 Configuring CLV with the user interface of CLV Setup, Page 6-4.
• Teach-in match code 1/activate match code comparison with "Sensor 2" switching input.
See Chapter 10.9.1 Triggering the teach-in match code 1 via the "Sensor 2" switching
input, Page 10-26.
• Show CP-limits
For monitoring purposes/correcting faults
• Displaying and editing operating data
• Reading diagnosis
• Monitor host interface
• Auxiliary input
• Self-test
6.5.1 Reading mode (standard operating mode)
The CLV performs a self-test after it has been switched on. It is then set to the reading mode
and confirms this by outputting two consecutive tones via the beeper. In the default setting,
the "Sensor 1" switching input is the (external) trigger source of the reading pulse. The
reading result is output by the CLV at the end of the reading pulse via the host interface
(default setting) and terminal interface.
The reading result of the terminal interface can be displayed in the CLV Setup terminal
emulator. The CLV terminal interface must be set to the
reading diagnosis mode for this
purpose. This mode is selected for the default setting. The reading result of the terminal
interface has a fixed, invariable format.
The READING MODE can be called up by choosing VIEW in the menu bar or via the terminal
emulator.
