Position Description Characteristic
5 Scanning method, reading window
orientation
1)
0: Line scanner, reading window on front
1: Grid scanner, reading window on front
2: Line scanner, reading window on side
3: Grid scanner, reading window on side
6: Line scanner with oscillating mirror,
reading window on side
6 Electrical connections (design) 0: Cable 0.9 m with male connector, D-
Sub-HD, 15-pin
1: Swivel connector, 12-pin (2 x M12 plug
connector
2)
)
3: Cable 2 m with male connector, D-Sub-
HD, 15-pin
8: Swivel connector, 17-pin (2 x M12 plug
connector
3)
)
7 Interfaces 0: RS-232, RS422/485, CAN,
digital IOs
4)
2: Ethernet, RS-232, RS422/485, CAN,
digital input
5)
3: Ethernet, RS-232, RS422/485, CAN,
digital IOs
4)
8 Front screen material 0: Glass
1: Plastic
9 Application (environment) 0: Standard (0 °C … + 40 °C)
F0: With mounted external heating
(‒35 °C … + 35 °C)
S01: IP 69K
Without label: IP65
1)
Refers to the longitudinal axis of the device.
2)
1 x male connector, M12, 12-pin, A-coding and 1 x female connector, M12, 4-pin, D-coding.
3)
1 x male connector, M12, 17-pin, A-coding and 1 x female connector, M12, 4-pin, D-coding.
4)
2 x digital switching inputs and 2 x digital switching outputs.
5)
1 x digital switching input.
NOTE
Not all possible combinations according to the type code are available. The available
device variants can be found online at:
•
www.sick.com/CLV63x
•
www.sick.com/CLV64x
•
www.sick.com/CLV65x
PRODUCT DESCRIPTION 3
8019588/2017-01-20 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
13
Subject to change without notice
