12 Technical data
12.1 Optical lens system
CLV63x CLV64x CLV65x
Focus Fixed focus Dynamic focus adjust‐
ment
Auto-focus/Dynamic
focus adjustment
Laser diode (wave‐
length)
Visible red light (λ = 655 nm) Visible red light (λ =
658 nm)
MTTF (laser diode) 40000 h
Laser class Class 2 according to IEC 60825-1 and EN 60825-1, see warning label
on the device for publication date
Usable aperture angle Front side: ≤ 50°
Reading window on
side: ≤ 51.5°
Front side: ≤ 50°
Reading window on side: ≤ 50°
Scan/Decoder fre‐
quency
400 Hz ... 1200 Hz 400 Hz ... 1200 Hz 600 Hz ... 1000 Hz
Resolution 0.20 mm ... 1.0 mm
(type-dependent)
0.15 mm ... 1.0 mm
(type-dependent)
0.25 mm ... 1.0 mm
(type-dependent)
Bar code print con‐
trast (PCS)
≥ 60 %
Ambient light immun‐
ity
2000 lx (on bar code)
12.2 Performance
CLV63x CLV64x CLV65x
Bar code types Code 39, code 128, code 93, Codabar, EAN, EAN 128, UPC, 2/5 Inter‐
leaved, Pharmacode
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART decoder)
No. of codes per read‐
ing interval
1 ... 50 (auto-discriminating)
No. of characters per
reading interval
Max. 50 characters (max. 5000 characters across all bar codes per
reading gate, 500 characters for multiplexer function (CAN))
Number of multiple
readings
1 ... 99
12.3 Interfaces
CLV63x CLV64x CLV65x
Serial (RS-232,
RS-422/-485)
Function: Host, AUX (RS-232 only)
Data transmission rate: 2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
Ethernet Ethernet versions only
Function: Host, AUX
Data transmission rate: 10/100 Mbit/s
Protocol: TCP/IP, EtherNet/IP, PROFINET Single Port
CAN bus Function: SICK CAN sensor network (master/slave, multiplexer/server)
Data transmission rate: 20 kbit/s ... 1 Mbit/s
Protocol: CSN (SICK CAN sensor network), CANopen (CLV65x only)
DeviceNet Optional, over external connection module (CDM)
12 TECHNICAL DATA
62
O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/2017-01-20 | SICK
Subject to change without notice
