6
GND (black)
7
F (fuse)
Control cabinet
CLV
Heating
Additional terminal (part number 6041383)
6.6 Wiring interfaces
6.6.1 Connecting the supply voltage
Connecting supply voltage to devices without heating
The device must be connected to a power supply unit with the following properties:
•
Supply voltage DC 24 V ± 20% (stabilized safety extra low voltage SELV as per cur‐
rently valid standards)
•
Electricity source with at least 30 W power
•
Additional 0.5 W output power when using the optional CMC600 parameter mem‐
ory module in the corresponding connection modules
Connecting supply voltage to devices with heating
NOTICE
Devices with heating must only be connected via a CDM420-0001 or CDB620-001 con‐
nection module.
A connection module must be used to connect the sensor to a power supply unit with
the following properties:
•
Supply voltage DC 24 V ± 10% (stabilized safety extra low voltage SELV as per cur‐
rently valid standards)
•
Electricity source with at least 40 W power
•
Additional 0.5 W output power when using the optional CMC600 parameter mem‐
ory module in the corresponding connection modules
Protecting the supply cables
To ensure protection against short-circuits and overload in the customer’s supply
cables, the conductor cross sections used must be appropriately selected and pro‐
tected.
The following standards must be observed in Germany:
•
DIN VDE 0100 (part 430)
•
DIN VDE 0298 (part 4) and/or DIN VDE 0891 (part 1)
The infeed of the supply voltage is carried out using a SICK connection module or the
customer's voltage supply.
6.6.2 Wiring data interfaces
Wiring Ethernet interface
1. Connect the device to the Ethernet connection of the PC via the adapter cable.
2. Set up communication via SOPAS ET configuration software.
ELECTRICAL INSTALLATION 6
8019588/2017-01-20 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
43
Subject to change without notice
