For 2-port devices, these include:
•
LLDP (neighborhood detection)
1
•
I&M 0-4 (device identification)
1
•
Device exchange by topology check
1
•
MRP (ring redundancy)
1
•
16 bit digital “status word” for reading gate result
•
16 bit digital “control word” for controlling the sensor via PLC
•
Heartbeat (for checking communication)
•
GSD file for configuring the sensor using modules via the PLC
1
14.1.6 Behavior of the switching outputs of the bar code scanner with “Fieldbus input” reading cycle
source
The digital outputs can be configured so that they can show information from other net‐
work participants (e.g. external output1=fieldbus input).
In the event that a fieldbus is interrupted, these outputs are no longer updated and
keep the last value that existed before the interruption.
After switching on the fieldbus (power-up), all digital outputs are set to their “passive”
values.
Status of digital outputs with output value behavior
IOPS = Bad Contain the last value before cancellation
Connection lost Contain the last value before cancellation
Switching on the PROFINET network Values are initialized to “passive”
The reading cycle input can also be controlled by the fieldbus. If the fieldbus is inter‐
rupted, the reading cycle input is no longer updated. Reading results can get lost since
the reading cycle input keeps the last value from before the interruption.
After switching on the fieldbus (power-up), the reading cycle input is set to its “passive”
value.
14.2 EU declaration of conformity / Certificates
The EU declaration of conformity and other certificates can be downloaded from the
Internet at:
b
www.sick.com/clv63x
b
www.sick.com/clv64x
b
www.sick.com/clv65x
14.3 Certification in accordance with UL60950
The bar code scanners of the CLV63x, CLV64x and CLV65x series are certified in
accordance with UL60950-1 if they are supplied with power by LPS or Class 2 network
devices. The UL certification applies for devices with heating with connecting cables of
up to 2 m in length.
The certification is only valid with corresponding device identification on the type label
of the respective bar code scanner, see "Type label", page 12.
14 ANNEX
76
O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/2017-01-20 | SICK
Subject to change without notice
